Bently Nevada 3300 Probe 146054-08-50-01-05 – Ceramic Capped

Description

Bently Nevada 3300 Ceramic Capped Proximity Probe

The 146054-08-50-01-05 is a high-precision proximity probe from Bently Nevada’s trusted 3300 series. It features a durable ceramic tip for extended life. This new, original unit comes in factory packing with a 12-month warranty.

Product Highlights

• Factory New & Original: Guaranteed genuine Bently Nevada quality.
• Robust Ceramic Tip: Alumina ceramic resists wear and harsh chemicals.
• Wide Temperature Range: Operates from -51°C to +177°C.
• High Pressure Rated: Seals up to 34 Bar (500 psi).
• Precision Measurement: Delivers accurate vibration and position data.
• Global Certifications: Includes CSA, ATEX, and IECEx approvals.
• Ready for Critical Machinery: Ideal for turbines, compressors, and pumps.

Ordering Code Breakdown

Part Number: 146054-08-50-01-05

• 146054: 3300 Ceramic Capped Probe, 3/8-24 UNF thread, without armor.
  • -08: Overall Case Length = 0.8 inches.
  • -50: Total Cable Length = 5.0 meters (16.4 feet).
  • -01: Connector Type = Miniature coaxial ClickLoc with protector.
  • -05: Agency Approval = CSA, ATEX, IECEx.

Detailed Specifications

Electrical Characteristics

• System Linear Range: 1.52 mm (60 mils).
• Linear Range Start Point: Approximately 0.25 mm (10 mils) from target.
• Incremental Scale Factor (ISF): 7.87 V/mm (200 mV/mil) ±6.5%.
• Probe Nominal Resistance (5m length): 8.73 Ohms ± 0.70 Ohms.
• Required Power Supply: -24 Vdc.
• Cable Impedance: 75 Ohm coaxial.

Mechanical Construction

• Probe Tip Material: High-purity Alumina Ceramic (Al2O3).
• Probe Case Material: AISI 304 Stainless Steel.
• Thread Specification: 3/8-24 UNF.
• Max Thread Engagement: 0.563 inches.
• Cable Insulation: Fluoroethylene Propylene (FEP).

Environmental & Operational Limits

• Operating/Storage Temperature: -51°C to +177°C (-60°F to +351°F).
• Pressure Seal Rating: 34 Bar (500 psi) with nitrogen.
• Frontal Target Material: Calibrated for AISI 4140 steel.
• Vibration & Shock: Built to withstand industrial plant conditions.

Warranty & Shipping Info

This product is covered by a full 12-month warranty against defects. We ship worldwide using express couriers: FedEx, UPS, and DHL. Tracking details are provided immediately after dispatch.

Typical Applications

• Gas & Steam Turbine Vibration Monitoring
• Centrifugal & Axial Compressor Protection
• High-Speed Pump Shaft Position Measurement
• Generator and Large Motor Monitoring
• Critical Machinery in Petrochemical Plants
