Bently Nevada 3300 XL 11mm Probe 330702-00-30-10-01-05 Vibration Sensor

Description

Product Introduction

Meet the Bently Nevada 3300 XL 11 mm Proximity Probe. This robust sensor delivers precise vibration and position data for critical machinery. It ensures reliable monitoring in harsh industrial environments. Its durable construction guarantees long-term performance. It is the trusted choice for predictive maintenance programs worldwide.

Key Specifications & Technical Data

• Brand & Model: Bently Nevada 330702-00-30-10-01-05
  • Series: 3300 XL
  • Type: 11 mm Proximity Transducer Probe
• Core Technical Parameters
  • Measurement Principle: Eddy current displacement sensing.
  • Target Material: Ferrous and non-ferrous conductive materials.
  • Probe Tip: Polyphenylene sulfide (PPS). Resists chemicals and wear.
  • Probe Resistance: 5.9 Ω ±0.5 Ω (Center to Outer Conductor for 1m cable).
  • Cable Impedance: 75 Ω triaxial.
  • Linear Range & Sensitivity: Defined by connected oscillator/demodulator.
  • Resolution & Frequency Response: Defined by connected monitor system.
• Physical & Mechanical Data
  • Case Material: AISI 304 Stainless Steel.
  • Thread Size: 1/2-20 UNF.
  • Thread Engagement: Max 0.750 in (19.05 mm).
  • Case Torque: Recommended 15.2 N•m (133 in•lb). Max 45.2 N•m.
  • Unthreaded Length: 0.0 in.
  • Overall Case Length: 3.0 in.
• Environmental & Operational Ratings
  • Temperature Range: -51°C to +177°C (Operating & Storage).
  • Low-Temp Note: Exposure below -34°C may affect the pressure seal.
  • Sealing: Viton O-ring seals probe tip to case from differential pressure.
  • Cable: FEP-insulated. 1.0 metre total length (standard for this variant).
  • Cable Bend Radius: Minimum 25.4 mm (1.0 in).
  • Connector: Miniature coaxial ClickLoc with protector.
  • Connector Torque: Finger tight. Max 0.565 N•m.
• Compatibility
  • Designed for seamless integration with Bently Nevada 3300 XL monitoring systems.
  • Works with compatible frame kits and extension cables.
• Certifications & Approvals
  • Agency Approval Option 05 denotes multiple international certifications for hazardous and industrial areas.
• Packaging & Shipping
  • Shipping Weight: 0.17 kg.
  • Packaging: Protective clamshell or box.
  • Shipping Methods: FedEx, UPS, DHL available.
  • Warranty: 12-month limited warranty from date of shipment.

Installation & Setup Guide

• Clean the mounting hole thoroughly before installation.
• Screw in the probe by hand initially to avoid cross-threading.
• Use a calibrated torque wrench. Tighten to the recommended 15.2 N•m.
• Do not exceed maximum thread engagement length.
• Route the cable carefully. Avoid sharp bends near the probe.
• Connect the ClickLoc connector securely until it clicks.
• For system setup, always refer to the primary monitor manual.

Maintenance & Diagnostics

• Ease of Maintenance: Modular design allows for simple probe replacement without recalibrating the entire system in many cases.
• Diagnostic Capability: When used with a 3300 monitor, system diagnostics can identify probe/cable faults (e.g., gap voltage, OK checks).
• Regularly inspect the cable jacket and connector for physical damage.
• Verify probe resistance (≈5.9Ω) during troubleshooting with a multimeter.
• Store spare probes within the specified temperature range.

Typical Applications

• Radial vibration measurement on turbine and compressor shafts.
• Axial position (thrust) monitoring on rotating equipment.
• Keyphasor® timing reference signal generation.
• Condition monitoring in oil & gas, power generation, and heavy industries.
• Critical machinery protection systems.

Frequently Asked Questions (FAQ)

General & Technical

Q: What is the main purpose of this probe?

A: It measures small changes in distance (vibration/position) of a metal shaft relative to the probe tip.

Q: Can I use this probe with a non-Bently Nevada system?

A: Not recommended. Performance requires matching to a compatible oscillator/demodulator.

Q: What does the “11 mm” refer to?

A: It is the diameter of the probe’s sensing tip.

Selection & Purchasing

Q: How do I choose the correct probe length?

A: Consider the mounting depth, required thread engagement, and necessary standoff from the casing. This model (3.0″ case, 0.0″ unthreaded) suits standard applications.

Q: What if I need a longer cable?

A: This specific part number includes a 1m cable. For 5m or 9m cables, you need a different suffix (e.g., -50 or -90).

Expert Tips

Q: What’s a common installation mistake?

A: Overtightening. This can damage threads or the probe body. Always use a torque wrench.

Q: Why does my new probe read incorrectly?

A: First, check the gap between the probe tip and the target shaft. Ensure it is set to the system’s required installation gap (e.g., 1.0 mm / 40 mils).

Buying Guidance

• Confirm your monitor system model is a Bently Nevada 3300 XL series.
• Verify the required thread size and probe length for your machinery’s mounting hole.
• Check the needed cable length from the probe to the junction box.
• For hazardous areas, ensure the approval option (05) meets your site requirements.
• Need help selecting? Contact our technical support via WhatsApp for expert advice.
