Bently Nevada 3300 XL 8mm Proximity Probe 330102-00-64-10-02-00

Description

Product Introduction

The Bently Nevada 330102-00-64-10-02-00 is a premium 3300 XL 8mm Proximity Probe. This sensor delivers precise vibration and position data. It protects critical machinery from unexpected failures. Essential for industrial predictive maintenance programs.

Product Model Breakdown: 330102-00-64-10-02-00

• 330102: 3300 XL 8mm Probe, 3/8-24 UNF thread, with armor.
• 00: Unthreaded Length = 0.0 inch.
• 64: Overall Case Length = 6.4 inches.
• 10: Total Cable Length = 1.0 meter (3.3 feet).
• 02: Connector = Miniature coaxial ClickLoc.
• 00: Agency Approval = Not required.

Technical Specifications

• Brand & Model: Bently Nevada 330102-00-64-10-02-00
• Series: 3300 XL 8 mm Proximity Probes
• Measurement Range: 2 mm (80 mils) linear range.
• Recommended Gap: -9 Vdc for radial vibration.
• Frequency Response: Consult manual for wiring effects.
• Sensitivity: Standard 8mm probe output.
• Linearity: Excellent from 0.25 to 2.3 mm.
• Resolution: High for detecting small changes.
• Temperature Range: -52°C to +177°C (Probe).
• Environmental Seal: Viton O-ring pressure seal.
• Humidity Rating: Stable in 93% humidity.
• Cable Length: 1.0 meter (3.3 feet).
• Connector: Miniature coaxial ClickLoc.
• Probe Resistance: 7.59 Ω ± 0.50.
• Tip Material: Polyphenylene sulfide (PPS).
• Case Material: AISI 303/304 Stainless Steel.

Installation Guide

• Maximum thread engagement is 0.563 inches.
• Set initial gap to achieve -9 Vdc output.
• Handle the PPS tip with care during installation.
• Use shielded triad cable for field wiring.
• Maximum field wiring: 305 meters (1000 feet).

Setup & Maintenance

• Calibration uses the -9 Vdc gap setting.
• Inspect cables and connectors regularly.
• Verify system output during machine runs.
• The probe itself requires no routine maintenance.

Compatibility Notes

• Works with Bently Nevada 3300 XL Proximitors.
• 1.0m cable suits standard 5m and 9m Proximitor models.

Certifications

• ATEX/IECEx: AEx/Ex ia IIC T5…T1 Ga.
• Zone 2: AEx/Ex nA IIC T5…T1 Gc.
• Meets North American safety standards.

Package & Warranty

• Includes: One 8mm Probe with connector.
• Backed by a 12-month warranty.
• Fast global shipping via FedEx, UPS, DHL.

Typical Applications & Diagnostics

• Monitor turbines, compressors, pumps, and fans.
• Measure shaft radial vibration and position.
• Diagnose imbalance, misalignment, and bearing wear.
• Core component of predictive maintenance.

Frequently Asked Questions (FAQ)

General Questions

• What is the standard gap voltage?
• Set the gap to achieve -9 Vdc output.
• What is the operating temperature?
• The standard probe works from -52°C to +177°C.

Expert Advice

• How do I select the right cable length?
• Match the cable to your Proximitor model. 1.0m is the versatile choice.
• The installation is in a cold environment. Any concerns?
• Temperatures below -34°C may affect the pressure seal long-term.

Purchasing Guidance

• Is this probe suitable for my compressor?
• It is a common fit. Always check your machine’s specific drawing.
• What else do I need for a working system?
• You need this probe, a compatible Proximitor, and a monitoring module.
