Description
Compact and Durable Vibration Sensor
The Bently Nevada 330101-00-36-05-02-00 is a precision vibration probe. It is designed for tight spaces. The probe measures shaft vibration and position. It helps predict machine failures. This model is made in the USA.
Your Model Code Explained
- 330101: 3300 XL 8mm Probe, 3/8-24 UNF thread, no armor.
- 00: Unthreaded Length = 0.0 inch.
- 36: Case Length = 3.6 inches.
- 05: Total Cable Length = 0.5 meter (1.6 feet).
- 02: Miniature coaxial ClickLoc connector.
- 00: Agency Approvals = Not required.
Main Features & Benefits
- Patented TipLoc: Strong bond between tip and body.
- Patented CableLoc: High pull strength of 330N (75 lbf).
- Short Cable: Perfect for installations with limited space.
- Robust 8mm Design: Thicker coil encapsulation for durability.
- High Temperature Rating: Operates from -52°C to +177°C.
Detailed Technical Specifications
- Product Type: 3300 XL 8mm Proximity Probe
- Thread: 3/8-24 UNF
- Linear Range: 2 mm (80 mils)
- Recommended Gap: -9 Vdc (approx. 1.27 mm / 50 mils)
- Sensitivity (ISF): 7.87 V/mm (200 mV/mil) ±5%
- Probe DC Resistance: 7.45 Ω ± 0.50 (for 0.5m cable)
- Extension Cable Capacitance: 69.9 pF/m typical
- Deviation from Linearity (DSL): Less than ±0.025 mm (±1 mil)
- Probe Tip Material: Polyphenylene sulfide (PPS)
- Case Material: AISI 303/304 Stainless Steel
- Seal Material: Viton O-ring
- Humidity Performance: Less than 3% change in 93% humidity
- Weight per Meter: 323 g/m (11.4 oz/ft)
Important Installation Notes
- Maximum field wiring length: 305 meters (1000 feet).
- Use shielded triad cable for best signal quality.
- Avoid temperatures below -34°C to protect pressure seal.
- Set initial gap to -9 Vdc for radial vibration monitoring.
Ordering & Warranty Information
- All products come with a 12-month warranty.
- Fast shipping available via FedEx, UPS, and DHL.
- Worldwide delivery with tracking number.
Frequently Asked Questions
Technical Questions
- Why choose a 0.5m cable instead of 1.0m?
- The 0.5m cable is ideal for compact installations where space is limited.
- What is the difference between this and armored probes?
- This model has no armor. It is lighter. Use armored probes in harsher physical environments.
Application Questions
- Can I order a FluidLoc cable for this probe?
- Yes, FluidLoc is an available option to prevent fluid leakage through the cable.
- What is the typical lifespan of this probe?
- With proper installation and within specifications, these probes last for many years.
Selection Advice
- Is the 8mm probe better than smaller sizes?
- Yes, the 8mm design offers more rugged construction. We recommend it when possible.
