Description
Overview
The Bently Nevada 3300 XL 8 mm Proximity Probe (Model 330103-00-10-05-02-00) is designed for high-precision vibration and position monitoring in non-hazardous industrial environments. Featuring a 100 mm stainless steel case (AISI 303/304) without armor, this probe offers flexibility for installations requiring lightweight design. Its 0.5-meter cable with a ClickLoc connector ensures easy integration, while the absence of agency certifications simplifies deployment. Engineered for durability, the probe operates across a wide temperature range of -52°C to +177°C and maintains accuracy in humid conditions, making it ideal for machinery in demanding settings.
Technical Specifications
| Category | Details |
|---|---|
| Brand | Bently Nevada |
| Model | 330103-00-10-05-02-00 |
| Suffix Breakdown | – 00: 0 mm unthreaded length – 10: 100 mm case length – 05: 0.5 m cable – 02: ClickLoc connector (standard) – 00: No agency approvals |
| Electrical | Input Voltage: -17.5 to -26 Vdc Output Resistance: 50 Ω Field Wiring Compatibility: 16–24 AWG shielded triad cable Max Cable Length: 305 meters (1,000 feet) |
| Mechanical | Probe Weight: 323 g/m (11.4 oz/ft) Thread Engagement: 15 mm (M10x1) Pressure Seal Material: Viton® O-ring |
| Certifications | Nonincendive Compliance: Class I/II/III, Div 2/Zone 2 (AEx/Ex nA/ec) Intrinsic Safety: Class I, Zone 0 (AEx/Ex ia) with barriers |
Contact Information
For custom pressure testing or hazardous area certifications:
Email: sales@ubestplc.com
