Description
Long-Case Metric Vibration Sensor
The Bently Nevada 3300 XL 8mm Probe offers deep mounting capability. Model 330103-00-16-10-01-00 features a 160mm case. It includes a protective connector cover for tough sites. This probe ensures stable machine monitoring.
Probe Configuration Breakdown
Your specific model, 330103-00-16-10-01-00, is detailed below.
- Base Model: 330103 (M10x1 Thread, No Armor)
- Unthreaded Length [00]: 0 mm (Fully Threaded)
- Case Length [16]: 160 mm (6.3 inches)
- Cable Length [10]: 1.0 meter (3.3 feet)
- Connector [01]: ClickLoc with Protector
- Agency [00]: Standard (No Special Approval)
Critical Technical Data
- Product Line: 3300 XL 8 mm Proximity Probes
- Mounting: M10 x 1.0 Metric Thread, 15mm max engagement.
- Installation Torque:
- Full Threads: 11.2 N•m recommended (100 in•lbf)
- First 3 Threads: 7.5 N•m recommended (66 in•lbf)
- Measurement: 2.0 mm linear range, set to -9 Vdc.
- Electrical: 7.59 Ω resistance (±0.50) for 1.0m length.
- Materials: Durable PPS tip, 303/304 Stainless Steel body.
- Seal: Reliable Viton® O-ring.
- Robust Design: Includes a connector protector (Option 01).
Environmental & Safety Ratings
- Operating Temperature: -52°C to +177°C (Standard).
- Hazardous Areas: Compatible with ia (Zone 0) and nA/ec (Zone 2) systems when used with proper safety interfaces.
- Consult the temperature schedule for specific T-class ratings.
Simple 4-Step Installation
- Ensure the mounting hole is clean and M10x1 threaded.
- Screw in the probe. Use a torque wrench for safety.
- Connect the ClickLoc cable. The protector guards the connection.
- Adjust the gap to get a -9 Vdc reading at the monitor.
Order Confidence & Delivery
- One (1) Bently Nevada 3300 XL 8mm Probe, part 330103-00-16-10-01-00.
- Warranty Promise: Full 12-month coverage against defects.
- Shipping: Quick dispatch via FedEx, UPS, or DHL worldwide.
Primary Uses
Ideal for applications needing a longer probe body. Perfect for deep mounting holes on gearboxes or large bearings. For different metric probe styles, view our 3300 NSv Probes.
Customer Questions Answered
Product Features Explained
- What is the connector protector in Option 01?
- It is a plastic cover that snaps over the ClickLoc connector. It protects the contacts from dust, moisture, and accidental impact in harsh environments.
- Why are there two different torque specifications?
- One is for engaging all threads in a deep hole. The lower value is for when only the first three threads are engaged, which provides less holding strength.
Application & Selection Advice
- When should I choose this 160mm case length?
- Choose this model when your mounting hole is deep, or you need the probe tip to reach past a thick machine casing or insulation layer.
- Can the connector protector be removed after installation?
- Yes, it is designed to be removable. This allows for inspection or reconnection while providing protection during normal operation.
