Product Introduction
Discover the Bently Nevada 330103-02-08-10-02-00. This is a high-performance 3300 XL 8mm Proximity Probe. It features a standard 80mm case with M10 metric thread. Perfect for accurate vibration monitoring in industrial applications.
Understanding Your Model Code
- Base Code: 330103
- Identifies an 8mm probe with M10x1 thread.
- Part of the 3300 XL vibration monitoring series.
- First Suffix: -02
- Indicates 20mm unthreaded length at probe tip.
- Provides better alignment during installation.
- Second Suffix: -08
- Specifies 80mm overall case length.
- Standard size for most mounting applications.
- Third Suffix: -10
- Denotes 1.0 meter cable length (3.3 feet).
- Balanced length for flexible installation.
- Fourth Suffix: -02
- Specifies Miniature ClickLoc connector.
- Standard cable connection without protector.
- Fifth Suffix: -00
- Indicates no special agency approvals.
- For general industrial use only.
Key Features & Benefits
- Metric Thread Design: M10x1 thread fits international equipment standards
- Optimal Length: 80mm case provides versatile mounting options
- Practical Cable: 1.0 meter length offers installation flexibility
- Robust Construction: 8mm diameter withstands physical stress
- Secure Connection: ClickLoc connector ensures reliable signal transmission
- Browse more options in our 3300 XL 8mm Probes collection
Technical Specifications
- Manufacturer: Bently Nevada
- Product Type: Proximity Vibration Probe
- Measurement Range
- Linear Range: 2.0 mm (80 mils)
- Effective Range: 0.25 to 2.3 mm from target
- Recommended Gap: -9 Vdc (approx. 1.27 mm)
- Electrical Characteristics
- Probe Resistance: 7.59 Ω ± 0.50 Ω at 1.0m
- Field Wiring: Shielded triad cable, max 305 meters
- Cable Capacitance: 69.9 pF/m typical
- Mechanical Specifications
- Thread Type: M10 x 1 metric
- Case Length: 80 mm total
- Unthreaded Section: 20 mm
- Max Thread Engagement: 15 mm
- Case Material: AISI 303/304 Stainless Steel
- Tip Material: PPS Plastic
- Environmental Ratings
- Operating Temperature: -52°C to +177°C
- Storage Temperature: Avoid below -34°C
- Humidity Resistance: Less than 3% change in 93% RH
- Pressure Seal: Viton® O-ring design
- Compliance & Safety
- Intrinsic Safety: Compatible with ia and nA/ec systems
- Requires external barriers for hazardous areas
- Standard industrial certification only
Installation Guidelines
- Clean M10x1 mounting thread before installation
- Use proper torque for secure mounting
- Ensure 20mm unthreaded section aligns properly
- Connect ClickLoc connector firmly
- Use recommended shielded field wiring
Package & Service Information
- Package Contents
- One Bently Nevada 3300 XL 8mm Probe
- Complete with integrated cable and connector
- Warranty: 12-month manufacturer warranty
- Shipping: Worldwide via FedEx, UPS, DHL
- Support: Contact us: +86 158 8020 0923 (WhatsApp)
Professional FAQ
Why choose 20mm unthreaded length over other options?
The 20mm unthreaded section provides stable alignment. It prevents thread damage during installation and ensures proper probe orientation.
How does cable length affect probe performance?
This 1.0 meter length offers optimal balance. It provides enough reach for installation while minimizing signal loss compared to longer cables.
What maintenance does this probe require?
Minimal maintenance needed. Regularly check connector integrity and cable condition. Verify resistance values during system calibration.
Can this probe handle high-vibration environments?
Yes. The 8mm diameter and robust construction make it suitable for high-vibration applications. The secure ClickLoc connector prevents disconnection.
What’s the most important installation check?
Always verify thread compatibility first. Ensure your equipment has M10x1 threads. Incorrect thread matching can damage both probe and equipment.
Selection Guide
- Confirm equipment uses M10x1 metric threads
- Check available space for 80mm probe length
- Ensure 1.0m cable meets your routing needs
- For hazardous areas, plan additional safety barriers
- All probes include 12-month warranty protection
- Fast shipping available with major carriers
