Description
Compact Armored Sensor for Tight Spaces
This is the Bently Nevada 330104-00-06-05-02-CN. It is an armored 3300 XL 8mm Proximity Probe with a short 60mm case. Perfect for installations with limited clearance. Offers robust protection and reliable performance in compact machinery layouts.
Model Code Structure
- Product Identifier: 330104-00-06-05-02-CN
- Segment 1 (00): Unthreaded Length = 0 mm
- Segment 2 (06): Case Length = 60 mm
- Segment 3 (05): Cable Length = 0.5 m
- Segment 4 (02): Standard ClickLoc Connector
- Segment 5 (CN): Country-Specific Approvals
Engineering & Performance Data
- Design: Armored Housing (330104 Series).
- Mounting: M10 x 1.0 mm Metric Thread.
- Materials: Stainless Steel Body, PPS Tip.
- Protection: Extra metal sheath for durability.
- Circuit: 7.45 Ω ± 0.5 DC Resistance.
- Measurement: 2.0 mm Linear Gap Range.
- Output: 7.87 V/mm (200 mV/mil) Scale Factor.
- Installation: Max 15 mm Thread Engagement.
- Conditions: -52°C to +177°C Operating Temp.
- Compliance: Meets Regional Safety Standards.
Included Items & Guarantee
- One Bently Nevada 330104-00-06-05-02-CN probe.
- Fully assembled and ready for use.
- Quality assurance documentation.
- Comprehensive 12-month warranty included.
Express delivery via FedEx, UPS, or DHL available. Need assistance? Chat with us on WhatsApp: +86 158 8020 0923.
FAQ: Application & Selection
What does “country-specific” (CN) approval mean?
This probe is built to meet the safety certification requirements of specific countries or economic regions, such as China or other local markets.
Why choose a 60mm case length?
The 60mm (approximately 2.4-inch) case is a compact option. It is ideal where space behind the mounting point is very limited.
Is the armored body heavier?
Yes, the armored version adds minimal extra weight for significantly improved physical protection against impacts and crushing.
Can this probe be used in a standard 3300 XL system?
Absolutely. This 330104 armored probe is fully electrically and mechanically compatible with standard 3300 XL driver and monitoring systems.
How do I order the correct approval variant?
Specify your project’s location and required certifications. We can help identify if this 330104-00-06-05-02-CN model is suitable or if another approval code is needed.
