Description
Overview
The Bently Nevada 3300 XL 8 mm Proximity Probe (Model 330104-00-20-05-02-00) delivers precise vibration and position monitoring for industrial machinery. Designed with durability in mind, this probe features an AISI 303/304 stainless steel case and a Polyphenylene sulfide (PPS) tip, ensuring resistance to harsh environments. Additionally, its Viton® O-ring seal maintains integrity under differential pressure, while the ClickLoc connector simplifies installation. Ideal for applications requiring high accuracy, the probe operates reliably between -17.5 Vdc and -26 Vdc, supporting systems up to 2000 meters altitude.
Technical Specifications
| Category | Details |
|---|---|
| Brand | Bently Nevada |
| Model | 330104-00-20-05-02-00 |
| Suffix Breakdown | – 00: 0 mm unthreaded length – 20: 200 mm case length – 05: 0.5 m cable – 02: ClickLoc connector – 00: No agency approval |
| Probe Material | Case: AISI 303/304 SST Tip: PPS Seal: Viton® O-ring |
| Electrical | Input: -17.5 to -26 Vdc Output Resistance: 50 Ω DC Resistance: 7.45±0.5 Ω |
| Environmental | Operating Temp: +18°C to +27°C Max Altitude: 2000 meters |
Contact Information
For inquiries or orders, contact our sales team at sales@ubestplc.com
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
