Bently Nevada 330190-045-00-00 Cable | Sensor Lead

Description

Product Overview

• Brand: Bently Nevada
• Model: 330190-045-00-00
• Series: 3300 XL ETR Extension Cable
• This cable supports stable signals in hot areas.
• Length is 4.5 m for long routing needs.
• PFA insulation enables strong heat endurance.

Technical Data

• Electrical Performance:
  • RCORE: 0.99 ±0.15 Ω
  • RJACKET: 0.30 ±0.06 Ω
  • Capacitance: 69.9 pF/m
  • Field wiring length: up to 305 m
  • Signal range: 0.25–2.3 mm
• Mechanical:
  • Cable bend radius: 25.4 mm
  • Weight: 34 g/m
  • Armored weight: 103 g/m
  • Connector torque: 0.565 N·m
• Materials:
  • Standard cable: FEP 75 Ω triaxial
  • ETR cable: PFA 75 Ω triaxial
  • Connector: Gold‑plated copper alloy
• Environmental:
  • Standard temp: −52°C to +177°C
  • ETR temp: −52°C to +260°C
  • Humidity stable for industrial use
• Certifications:
  • FCC Part 15
  • EN 61000-6-2, EN 61000-6-4
  • RoHS 2011/65/EU
  • Marine 2019 rules
  • SIL2 (HFT 0), SIL3 (HFT 1)
• Compatibility: Fits 3300 XL 8 mm and 5 mm systems.

Product Benefits

• Good heat resistance for tough sites.
• Stable signal in long runs.
• Strong outer jacket for long life.
• Low noise for clean readings.
• Easy routing due to slim form.

Installation Guide

• Keep bend radius above 25.4 mm.
• Use shielded triad for field wiring.
• Do not twist the connector body.
• Gap near −9 Vdc for radial checks.

Maintenance Tips

• Check connector torque yearly.
• Inspect for jacket cuts.
• Keep cable away from sharp heat sources.
• Confirm resistance during shutdown.

Shipping Options

• FedEx
• UPS
• DHL

Warranty

• 12‑month warranty for defects

FAQ

• Can I run this cable near power lines?
  Keep some space to reduce noise.
• How do I prevent signal loss?
  Use shorter field wiring where possible.
• Does heat change readings?
  ETR design keeps values stable.
• What if the cable gets bent too far?
  Check for jacket damage and measure resistance.
• How do I verify correct routing?
  Follow the shielded‑triad plan from the monitor side.
