Description
Short-Case Probe for Tight Spaces
The Bently Nevada 330707-00-20-10-01-00 is a compact 3300 XL 11 mm Proximity Probe. It features a short 2.0-inch case with a robust 5/8-18 thread. The 1-meter cable makes installation neat and easy in confined areas. This probe provides precise vibration measurement for motor and pump monitoring. Built in the USA to the highest standards.
Product Configuration Tree
Your probe’s part number reveals its specific design: 330707-00-20-10-01-00.
- Base Model: 330707 (11mm, Unarmored)
- ➤ Variant 1 [00]: Unthreaded Length = 0.0 in
- ➤ Variant 2 [20]: Overall Case Length = 2.0 in
- ➤ Variant 3 [10]: Total Cable Length = 1.0 m
- ➤ Variant 4 [01]: Connector = ClickLoc with Protector
- ➤ Variant 5 [00]: Agency Approvals = Not Required
Specifications Summary
- Identification
- Manufacturer: Bently Nevada
- Part Number: 330707-00-20-10-01-00
- Product Family: 3300 XL 11 mm Proximity Probes
- Country of Origin: U.S.A.
- Key Physical & Electrical Data
- Case Thread: 5/8-18 UNF (also fits M16x1.5)
- Case Length: 2.0 inches
- Integrated Cable: 1.0 metre (3.3 feet)
- Probe Resistance: 5.9 ± 0.5 ohms (for 1m length)
- Cable Specification: 75 Ω Triaxial, FEP Insulated
- Construction: 304 SST Case, PPS Tip, Viton Seal
- Performance & Environment
- Operating Temperature: -51°C to +177°C
- Seal Care: Avoid sustained use below -34°C
- Bend Radius: Minimum 25.4 mm (1.0 inch)
- Installation Guidance
- Mounting Torque: Recommended 15.2 N·m (133 in·lb)
- Maximum Torque: 45.2 N·m
- Connector: Finger-tight only (Max 0.565 N·m)
Ordering & Support Details
- Package Includes: One probe unit with attached cable.
- Shipping Weight: 0.17 kg.
- Global Delivery: We ship via FedEx, UPS, and DHL.
- Warranty Coverage: Full 12-month warranty provided.
FAQ for This Model
What is the main advantage of the 2-inch case?
It allows installation in locations with very limited axial space behind the mounting point.
Is the M16x1.5 thread metric equivalent to 5/8-18?
They are similar in size and often interchangeable in many industrial mounting holes.
Can I use this unarmored cable in a harsh environment?
It is suitable for general industrial use. For severe abrasion or crush risk, choose an armored probe.
From Experience: How do I handle the short cable during routing?
Plan the cable path carefully. Use cable ties and avoid sharp bends to protect the connection point.
Buying Guide: I need a probe for a European machine with M16 threads. Will this fit?
Yes. The 330707-00-20-10-01-00 with its 5/8-18 thread is compatible with standard M16x1.5 mounting holes.
