Description
Bently Nevada 330707-00-20-50-12-05 Industrial Probe
This is the genuine Bently Nevada 330707-00-20-50-12-05. It’s a 5-meter armored 3300 XL 11 mm Proximity Probe with multiple safety certifications. Made in the USA for reliable monitoring.
Product Configuration & Build
- Base Model: 330707 (3300 XL 11mm Probe, 1/2-20 UNF, Armored)
- Configuration Tree:
- Probe Base: 330707 → 11mm, 1/2-20 thread, armored
- Option 00 → 0.0 in unthreaded length
- Option 20 → 2.0 in case length
- Option 50 → 5.0 meter total length (16.4 ft)
- Option 12 → ClickLoc connector, FluidLoc cable
- Option 05 → Multiple Approvals certified
Key Specifications & Ratings
- Sensor Type: 11mm Eddy Current
- Thread: 1/2-20 UNF
- Cable: 5.0 meters, 75 Ω Triaxial, FluidLoc type
- Resistance: 7.2 ± 0.8 ohms (center to outer conductor)
- Temp Range: -51°C to +177°C (-60°F to +351°F)
- Materials: SST case, PPS tip, armored cable
- Certifications: Multiple international safety approvals
- Weight: 0.17 kg shipping weight
Installation & Usage Guidelines
- Mounting Torque: Apply 15.2 N•m (133 in•lb). Maximum is 45.2 N•m.
- Thread Engagement: Do not exceed 0.750 inches.
- Connector Handling: Connect finger tight only. Maximum torque 0.565 N•m.
- Cable Care: Maintain minimum 25.4 mm (1.0 in) bend radius.
- Cold Installation: Avoid installing below -34°C to prevent seal damage.
- System Match: Use only with 5-meter Proximitor Sensors.
Expert FAQ & Buying Support
Q: What industries need this probe with “Multiple Approvals”?
A: The 330707-00-20-50-12-05 is essential for regulated sectors like oil & gas, chemical, and power generation where strict safety certifications are mandatory.
Q: How does FluidLoc cable differ from standard cable?
A: FluidLoc cable has enhanced sealing to resist oil, water, and chemical ingress. It offers better protection in wet or harsh industrial environments.
Q: Can I use this 5-meter probe with any monitor?
A: No. It is specifically designed for use with Bently Nevada 5-meter Proximitor Sensors only. Using it with other lengths may cause signal issues.
Q: What warranty comes with this probe?
A> We provide a full 12-month manufacturer’s warranty on the 330707-00-20-50-12-05, covering defects in materials and workmanship.
Q: What are the shipping costs and times?
A: We offer competitive shipping via FedEx, UPS, and DHL. Costs and delivery times vary by destination and are calculated at checkout.
Have a specific application question? Contact us on WhatsApp: +86 158 8020 0923
Browse our full selection of 3300 XL 11 mm Proximity Probes for all your monitoring needs.
