Bently Nevada 330707-00-20-90-02-00 | 9-Meter Cable 5/8-18 UNF Vibration Probe

Description

Product Overview: Long-Reach Heavy-Duty Probe

This 3300 XL 11 mm Proximity Probe combines a large thread with a long cable. The 5/8-18 UNF thread ensures a secure mount in heavy machinery. It comes with a full 9-meter cable for distant monitors. This design is perfect for large equipment layouts. It delivers reliable vibration data to protect your critical assets.

Technical Product Breakdown

• Brand: Bently Nevada
• Series: 3300 XL Monitoring System
• Detailed Part Number: 330707-00-20-90-02-00
  • Model Root: 330707 (11mm, 5/8-18 UNF, No Armor)
  • Segment 00: Unthreaded Probe Length = 0 inches
  • Segment 20: Probe Case Length = 2.0 inches
  • Segment 90: Integrated Cable Length = 9.0 meters
  • Segment 02: Connector Type = Miniature ClickLoc
  • Segment 00: Agency Approvals = Not Required
• Core Performance Specifications:
  • Measurement Capability: Accurate vibration and position sensing.
  • Frequency Response: Matches 3300 XL system requirements.
  • Sensitivity & Resolution: High-fidelity signal output.
  • Wide Temperature Range: -51°C to +177°C.
  • Environmental Toughness: Built for demanding industrial sites.
  • Noise Immunity: Stable operation in electrically noisy areas.
• Physical & Electrical Data:
  • Mounting Thread: Robust 5/8-18 UNF.
  • Case Material: AISI 304 Stainless Steel.
  • Sensing Tip: Polyphenylene Sulfide (PPS).
  • Cable Type: 75-ohm Triaxial, FEP insulated, 9m long.
  • DC Resistance (9m): 8.5 ± 1.1 ohms.
  • Installation Torque: 15.2 N•m recommended.
  • Max Thread Engagement: 0.938 inches.
  • Minimum Bend Radius: 25.4 mm.

Installation Procedure

• Install into a clean 5/8-18 UNF threaded hole.
• Ensure thread engagement does not exceed 0.938 inches.
• Tighten the probe case to 15.2 N•m using a torque wrench.
• Connect the ClickLoc connector by hand – do not use tools.
• Carefully route the long 9-meter cable, avoiding sharp bends.
• Protect the probe from temperatures below -34°C to maintain seal integrity.
• For custom pressure testing needs, contact our design team.
• Quick question? Reach our technical support on WhatsApp.

Calibration & Ongoing Care

This probe integrates directly with Bently Nevada 3300 XL monitors. Set the system gap voltage per your machinery specs. The long cable allows flexible monitor placement. Regularly check the cable sheath for cuts or abrasion.

System Integration

Engineered for the 3300 XL monitoring platform. The standard ClickLoc connector ensures a positive lock. Confirm your monitor is compatible with this probe type and cable length.

Certifications & Compliance

The -00 approval option indicates this model ships without specific agency certifications. It is manufactured to Bently Nevada’s high industrial quality standards.

What You Receive & Our Commitment

• One genuine Bently Nevada 330707-00-20-90-02-00 vibration probe.
• Associated product documentation.
• Fast Shipping: We dispatch globally via FedEx, UPS, and DHL.
• Quality Warranty: This product is covered by a 12-month warranty.

Primary Applications

Ideal for large turbines, generators, and compressors where the monitor is located far away. The 5/8-18 thread provides extra mechanical security in high-vibration environments. A key component for comprehensive predictive maintenance strategies.

Technical FAQ

Product Details & Selection

• • Why is the case length only 2.0 inches in this model?
  • The -20 case length option is shorter than standard. It is used when space behind the mounting surface is limited, but a long cable run to the monitor is still needed.

• What does “agency approval not required” mean?
• For the 330707-00-20-90-02-00, it is not certified for use in legally regulated hazardous (Ex) areas. It is intended for standard industrial environments.

Installation & Best Practices

• • How should I manage the excess 9-meter cable?
  • Coil any excess neatly in a protected location. Use large-diameter loops (over 50mm) to avoid sharp bends that can damage the internal conductors.

• What is a field-proven tip for installing long-cable probes?
• Route and secure the entire cable path *before* final tightening of the probe. This prevents twisting strain on the probe’s internal connections during installation.

Purchasing & Support

• • My application requires hazardous area approval. Can you help?
  • Yes. You need a model with the -05 approval suffix instead of -00. Contact us to find the correct certified version of the 330707 probe for your site.

• What is included in your 12-month warranty?
• It covers defects in materials and workmanship. If your 330707-00-20-90-02-00 probe fails under normal use within 12 months, we will replace or repair it.
