Bently Nevada 330707-00-20-90-12-00 | 9m FluidLoc 11mm Vibration Probe

Description

Long-Range, Heavy-Duty Vibration Monitoring

Engineered for demanding environments, the Bently Nevada 3300 XL 11 mm Proximity Probes deliver reliability. Model 330707-00-20-90-12-00 combines extreme reach with superior environmental protection. Its 9-meter FluidLoc cable and 5/8-18 UNF thread make it perfect for wet, large-scale industrial applications where sensors are far from the monitor.

Key Product Advantages

• Maximum Distance Coverage: 9.0-meter cable for remote monitoring setups.
• Environmental Defense: FluidLoc cable resists water, oil, and chemicals.
• Robust Mounting: 5/8-18 UNF thread for secure installation on heavy machinery.
• Extended Case Length: 2.0-inch case provides standard mounting depth.
• Wide Thermal Range: Operates reliably from -51°C to +177°C.

Configuration Decoder: 330707-00-20-90-12-00

• Product Line: 330707 (3300 XL 11mm Probe, Unarmored)
• Option-by-Option Analysis:
  • Field 1 [00]: Unthreaded Length
    • Interpretation: 0 inches. The entire case body is threaded.
  • Field 2 [20]: Case Dimensions
    • Interpretation: 2.0 inches long. This is a common, standard case length.
  • Field 3 [90]: Cable System
    • Interpretation: 9.0 meters of integrated, attached cable.
    • Note: This is the longest available factory cable option.
  • Field 4 [12]: Connection & Protection
    • Interpretation: Miniature Coaxial ClickLoc connector with FluidLoc cable.
    • This is the key feature for moisture resistance.
  • Field 5 [00]: Certification Status
    • Interpretation: No special agency approvals. Standard industrial model.

Technical Specifications

• Electrical Characteristics:
  • Probe Resistance (9m system): 8.5 Ω ± 1.1 Ω
  • Cable Construction: 75 Ω Triaxial, FEP Insulated, FluidLoc Sheath
• Mechanical Specifications:
  • Mounting Thread: 5/8-18 UNF
  • Max Thread Engagement: 0.938 inch
  • Installation Torque (Optimal): 15.2 N•m
  • Absolute Max Torque: 45.2 N•m
  • Cable Bend Minimum: 25.4 mm radius
• Material Composition:
  • Probe Body: AISI 304 Stainless Steel
  • Sensing Tip: PPS Plastic
  • Internal Seal: Viton O-ring

What’s Included & Our Promise

• Your Order Includes: One 9-meter probe with ClickLoc connector and FluidLoc cable.
• Quality Assurance: Protected by a comprehensive 12-month warranty.
• Rapid Delivery: Shipped globally via FedEx, UPS, or DHL express services.
• Direct Support: Technical Inquiries: +86 158 8020 0923 (WhatsApp)

Frequently Asked Questions

Product Application

• Q: What makes the 330707-00-20-90-12-00 ideal for paper mills or chemical plants?
• A: The combination of a long 9m cable and the FluidLoc sheath is key. It allows installation far from control rooms while protecting the cable from moisture, steam, and chemical splash common in those environments.

Specifications & Compatibility

• Q: Is the 2.0-inch case length a standard size?
• A> Yes. The 2.0-inch case in model 330707-00-20-90-12-00 is the most common length. It fits standard mounting holes and provides a good balance of strength and installation clearance.
• Q: Can I use this 9-meter probe with any monitor, or do I need a special driver?
• A: This probe is electrically designed for a 9-meter system. You must pair it with a compatible monitor (e.g., Bently Nevada 3300 XL) that is configured or can be calibrated for a 9-meter probe system to ensure accurate readings.

Purchasing & Support

• Q: How does FluidLoc cable differ from standard cable in wet areas?
• A> FluidLoc cable has a special outer jacket that provides a superior seal at the connector. This greatly reduces the risk of moisture traveling along the cable conductors, which can cause signal noise or failure in damp conditions.
• Q: What is your shipping policy for such a long cable? Can it get damaged?
• A> We coil and pack the 9-meter cable securely to prevent kinks. All shipments are insured. Our 12-month warranty covers any transit damage. We work with reliable carriers (DHL, FedEx, UPS) for safe, tracked delivery.

Buyer’s Checklist

• Confirm Requirement: You need an 11mm probe for a long-distance run (approx. 9 meters).
• Verify Mounting: Your equipment must have a 5/8-18 UNF threaded hole.
• Assess Environment: Choose 330707-00-20-90-12-00 specifically for wet, humid, or wash-down areas due to its FluidLoc cable.
• Check System Match: Ensure your vibration monitor supports a 9-meter probe system.
• Place Secure Order: Benefit from professional packaging and fast courier options.
• Need Verification? Confirm your application with us: +86 158 8020 0923.
