Bently Nevada 330707-00-30-10-02-05 Probe | 5/8-18 UNF 11mm Vibration Sensor

Description

Product Overview: Heavy-Duty Thread Vibration Probe

The Bently Nevada 3300 XL 11 mm Proximity Probe features a larger 5/8-18 UNF thread. This robust design is ideal for high-vibration machinery. It provides precise shaft vibration and position measurement. Its unarmored design offers a versatile mounting solution. Ensure your critical assets are monitored reliably.

Complete Technical Specifications

• Brand: Bently Nevada
• Product Family: 3300 XL Vibration Monitoring
• Full Model Identification: 330707-00-30-10-02-05
  • Series: 3300 XL 11mm Probe (5/8-18 UNF, No Armor)
  • Variant -00: Unthreaded Shank Length = 0.0 inch
  • Variant -30: Total Case Length = 3.0 inches
  • Variant -10: Total Cable Length = 1.0 meter
  • Variant -02: Connection = Miniature ClickLoc Connector
  • Variant -05: Certifications = Multiple Agency Approvals
• Key Performance Data:
  • Measurement Range: Optimized for standard machinery gaps.
  • Frequency Response: Compatible with 3300 XL system requirements.
  • Sensitivity & Linearity: High accuracy across its working range.
  • Operating Temperature: -51°C to +177°C (-60°F to +351°F).
  • Environmental Resistance: Built for tough industrial conditions.
  • Interference Immunity: Stable signal in electromagnetically noisy areas.
• Construction & Installation Details:
  • Thread Size: Larger 5/8-18 UNF for secure mounting.
  • Case Material: Durable AISI 304 Stainless Steel.
  • Tip Material: Wear-resistant Polyphenylene Sulfide (PPS).
  • Cable: 75 Ω Triaxial with FEP insulation (1m length).
  • Electrical Resistance (1m): 5.9 ± 0.5 ohms.
  • Installation Torque: 15.2 N•m recommended for case.
  • Max Thread Engagement: 0.938 inches.
  • Cable Bend Radius: Minimum 25.4 mm.

Installation Instructions

• Mount in a clean 5/8-18 UNF threaded hole.
• Do not exceed 0.938 inches of thread engagement.
• Apply 15.2 N•m torque for a secure, sealed fit.
• Connect the ClickLoc connector by hand only.
• Route the 1-meter cable with gentle bends.
• For pressure seal verification, contact our custom department.
• Installation help? Chat with our engineers on WhatsApp.

Calibration & Maintenance

Pairs seamlessly with Bently Nevada 3300 XL monitors. Set gap voltage per your machinery specifications. Perform visual inspections for cable damage. Avoid exposing the probe to temperatures below -34°C to protect the seal.

System Compatibility

Designed for integration with the 3300 XL monitoring series. The standard ClickLoc connector ensures reliable connection. Verify compatibility with your specific monitor frame and power supply.

Certifications & Safety

The -05 suffix indicates multiple international approvals. This probe meets stringent safety and performance standards for global use.

Package & Service Information

• One Bently Nevada 330707-00-30-10-02-05 vibration probe.
• Standard product documentation.
• Global Logistics: Shipped via FedEx, UPS, or DHL.
• Customer Assurance: Comes with a 12-month product warranty.

Typical Applications

Ideal for heavy machinery like large turbines, compressors, and industrial fans. The 5/8-18 thread provides extra strength in high-vibration environments. Essential for predictive maintenance programs on critical rotating assets.

Expert FAQ

Product Selection

• • What is the difference between the 5/8-18 and 1/2-20 thread models?
  • The 5/8-18 thread (330707) is larger and stronger. It is often used in applications with higher vibration or where a more robust mechanical connection is required.

• Does “without armor” affect the probe’s durability?
• The “armor” refers to external cable protection. The 330707-00-30-10-02-05 probe is still very durable. The unarmored cable is more flexible for easier routing in tight spaces.

Technical & Usage

• • Why is thread engagement length important?
  • Proper engagement ensures a tight mechanical seal and good electrical grounding. Exceeding 0.938 inches on this model could damage threads or hinder proper seating.

• From field experience, what ensures the longest probe life?
• Avoiding thermal shock and physical impact on the tip. Also, ensure the mating thread in your machine is clean and undamaged before installation to prevent cross-threading.

Purchasing & Support

• • How do I confirm this is the correct replacement part?
  • Match the thread size (5/8-18 UNF) and connector type (ClickLoc) from your old probe. The part number 330707-00-30-10-02-05 must match exactly for guaranteed compatibility.

• What if I need a different cable length?
• The -10 option is for a 1-meter cable. We also stock models with 5m (-50) and 9m (-90) cables. Contact us to find the right variant.
