Bently Nevada 330709-000-050-50-02-00 – Compact 11mm Proximity Probe
Full Part Number Breakdown
330709-000-050-50-02-00 ├─ 000 = 0mm unthreaded ├─ 050 = 50mm case length ├─ 50 = 5.0m cable (16.4ft) ├─ 02 = ClickLoc connector └─ 00 = No agency approvals
New Technical Parameters
- ⚡ Cable Type: 75Ω triaxial (FEP insulation)
- ???? Thread Specs: M16x1.5 (24mm max engagement)
- ???? Case Material: AISI 304 stainless steel (SST)
- ????️ Temp Drift: -3.96% scale factor @65°C (150°F)
Unique Applications
- ???? Paper Machinery: Monitor calender roll alignment in high-pressure zones
- ⛏️ Mining Crushers: Detect bearing misalignment in rock-processing equipment
- ✈️ Aero Engines: Measure turbine blade tip clearance during test runs
Model Comparison
| Model | Case Length | Cable Length | Typical Use | Product Link |
|---|---|---|---|---|
| 330709-000-070-10-02-00 | 70mm | 1.0m | Small machinery | View |
| 330709-000-080-10-02-00 | 80mm | 1.0m | General industrial | Specs |
| 330709-000-050-50-02-00 | 50mm | 5.0m | Remote/confined spaces | Current Model |
Critical Installation Notes
- ⚠️ Cold Limit: Avoid sustained use below -34°C (-30°F)
- ???? Target Requirement: Min 30.5mm flat / 152mm shaft diameter
- ???? Torque: 21.1N·m (187in·lb) recommended for M16x1.5 thread
