Bently Nevada 330710-000-050-50-02-CN 11 mm Proximity Probes Metric

Description

Bently Nevada 330710-000-050-50-02-CN – China-Certified Armored Proximity Probe

Full Part Number Breakdown

330710-000-050-50-02-CN
├─ 000 = 0mm unthreaded section
├─ 050 = 50mm case length
├─ 50 = 5.0m cable (16.4ft)
├─ 02 = ClickLoc connector
└─ CN = China-specific approvals

New Technical Parameters

• ????️ Armor Type: AISI 304 stainless steel (corrosion-resistant)
• ⚡ Resistance: 7.2Ω ±0.8Ω (5.0m cable)
• ???? Target Size: Min 30.5mm flat / 152mm shaft (prevents signal crosstalk)
• ✅ Certifications: GB/T 2423 (China environmental test standard)

Performance Highlights

• ???? Thread Torque: 187in·lb (21.1N·m) for secure mounting in vibrating machinery
• ????️ Temp Stability: -52°C to +177°C (-62°F to +351°F) (suitable for northern/southern China climates)
• ???? Cable Specs: 75Ω triaxial (FEP insulation) for stable signals in noisy factory floors

Installation Tips for China Users

• ⚠️ Cold Regions: Avoid temps < -34°C (-30°F) in Inner Mongolia (prevents pressure seal failure)
• ???? Warm Regions: Use 25.4mm bend radius in Guangdong (prevents cable kinks in high-humidity)
