Bently Nevada 330901-00-18-70-02-CN 3300 NSv Probe 330901 | 7.0m Vibration Sensor

Description

Product Introduction

The Bently Nevada 330901-00-18-70-02-CN is a high-performance 3300 NSv Proximity Probe. It provides precise measurement of shaft vibration and position. This version features a long 7.0-meter cable with a convenient Miniature ClickLoc connector. Its robust stainless steel construction ensures reliable operation in demanding environments. Need technical help? Contact us via WhatsApp: +86 158 8020 0923.

Technical Specifications

• Brand & Series: Bently Nevada 3300 NSv
• Full Model Number: 330901-00-18-70-02-CN
  • 330901: 1/4-28 UNF Thread Probe
  • 00: 0″ Unthreaded Length
  • 18: 1.8″ Case Length
  • 70: 7.0m Total Cable
  • 02: ClickLoc Connector
  • CN: Country Approval
• Core Function: Eddy-current displacement sensing.
• Measurement Range: Standard linear range.
• Frequency Response: 0 to 10 kHz.
• Sensitivity: Standard 200 mV/mil.
• Linearity: High within target range.
• Resolution: Excellent for fine details.
• Operating Temperature: -52°C to +177°C.
• Environmental Tolerance: Built for harsh conditions.
• Noise Immunity: Shielded coaxial design.
• Cable & Resistance:
  • 75 Ω FEP Coaxial Cable.
  • DC Resistance: 5.9 ± 0.9 ohms.
• Construction:
  • Case: AISI304 Stainless Steel.
  • Tip: PPS Material.
  • Seal: Viton O-ring.

Installation Guide

• Follow the thread engagement limit.
• Use the recommended 11.3 N•m torque.
• Never exceed maximum torque ratings.
• Ensure a proper target surface.
• For 8mm probes, see the 3300 XL 8mm Probe here.

Setup & Maintenance

• ClickLoc allows for fast installation.
• Inspect cables regularly for damage.
• Recalibrate during machine service.
• Store within allowed temperature limits.

Compatibility Notes

• Designed for the 3300 NSv monitoring system.
• Works with compatible monitors using the same sensitivity.
• Verify connector type matches your system.

Certifications & Package

• Holds country-specific (CN) approvals.
• Includes one probe assembly.
• Full 12-month manufacturer warranty.

Shipping Options

We ship worldwide using FedEx, UPS, and DHL for speed and reliability.

Applications & Diagnostics

• Monitor vibration on turbines, fans, and compressors.
• Measure shaft position and runout.
• Detect imbalance, misalignment, and bearing wear.
• Enable predictive maintenance to avoid downtime.

Frequently Asked Questions (FAQ)

Q: What does the ’70’ in the part number mean?

A: It specifies the total cable length is 7.0 meters.

Q: Is the connector easy to use?

A: Yes, the ClickLoc connector provides a secure, tool-free click connection.

Q: How much should I tighten the probe?

A: Use 100 in-lbs (11.3 N•m) of torque. Do not over-tighten.

Q: Can I use this probe in freezing temperatures?

A: It can operate down to -52°C, but try to avoid long periods below -34°C to protect the seal.

Q: From experience, what’s the most common mistake during installation?

A: Incorrect thread engagement or over-tightening. Always follow the specified limits to avoid damage.

Q: I’m not sure which probe model I need. What should I check?

A> First, identify your monitor system model. Then, note the required thread size, cable length, and connector from your old probe or manual. Match these to the part number codes. We can help you confirm.
