Description
Bently Nevada 3300 NSv Proximity Probe with FluidLoc Cable
PRODUCT HIGHLIGHTS
New original 330903-00-03-05-12-05 with 30mm case and FluidLoc cable. Factory sealed with 12-month warranty. Enhanced for wet environments.
SUFFIX CONFIGURATION
- Base Model: 330903 (NSv Probe, M8X1)
- -00- : 00 mm unthreaded length
- -03- : 30 mm overall case length
- -05- : 0.5 meter cable
- -12- : ClickLoc connector with FluidLoc cable
- -05 : Multiple agency approvals
CRITICAL SPECIFICATIONS
- FluidLoc Cable: Oil-resistant FEP insulation
- Case Dimensions: 30mm length × M8x1 thread
- Electrical Output: -1 to -13 Vdc linear range
- Environmental: IP67 equivalent sealing
- Temp Resilience: -52°C to +177°C continuous
- Vibration Tolerance: 15g @ 2kHz max
PERFORMANCE DATA
- Dynamic Response
- Rise time: 18 μs typical
- Phase shift: <3° @ 5 kHz
- Cable Specifications
- Capacitance stability: ±2% over temp range
- Shield effectiveness: 90 dB @ 30 MHz
MODEL COMPARISON
| Feature | This Model (330903-00-03-05-12-05) | 330903-00-05-05-01-00 | 330903-00-05-05-11-00 |
|---|---|---|---|
| Case Length | 30mm | 50mm | 50mm |
| Cable Type | FluidLoc (oil resistant) | Standard | High-temp |
| Approvals | Multiple (-05) | Standard (-00) | Standard (-00) |
| Best For | Wet environments | General purpose | High-temp areas |
FLUIDLOC ADVANTAGES
- Resists oils, coolants, and hydraulic fluids
- 30% better chemical resistance than standard cables
- Reduced swelling in hydrocarbon environments
- Maintains flexibility at -40°C
INSTALLATION NOTES
- Mounting Depth: Max 12mm thread engagement
- Gap Calibration: 1.0mm optimal (adjust ±0.2mm)
- Cable Routing: Min 25.4mm bend radius
- Wet Environment Tip: Apply silicone grease to threads
PACKAGE & WARRANTY
- ESD-protective packaging
- 12-month defect warranty
- Global shipping: DHL/FedEx/UPS 2-5 days
