Description
Bently Nevada 3300 NSv Proximity Probe – M8X1 Thread (5m Cable)
Factory new vibration sensor with FluidLoc technology for harsh environments. Direct replacement for 3300 RAM probes. 12-month warranty included.
Key Advantages
- 30mm compact case length for tight spaces
- Enhanced chemical resistance vs older models
- Wide temperature range (-62°F to +351°F)
- Protected ClickLoc connector system
- 5-meter ready-to-use cable (16.4 ft)
Technical Specifications
| Part Number: | 330903-00-03-50-11-00 |
| Thread: | M8X1 metric |
| Measurement Range: | 0.25-1.75mm (10-70 mils) |
| Output Signal: | -1 to -13 Vdc |
| Accuracy: | ±0.06mm (±2.3 mils) |
| Cable Type: | 75Ω coaxial FEP insulated |
Installation Guide
- Clean mounting surface thoroughly
- Hand-start threads to prevent cross-threading
- Final torque: 5.1 N•m (45 in-lb)
- Maintain minimum 25.4mm cable bend radius
- Set initial gap to 1.0mm (40 mils)
FAQ
Q: Is this compatible with 3300 RAM systems?
A: Yes, fully compatible with existing 3300 RAM installations.
Q: What’s the maximum cable length?
A: Up to 305m (1000ft) between probe and monitor.
Q: What’s included?
A: Probe, 5m FluidLoc cable, connector protector. No certificates included.
