Bently Nevada 330903-00-05-05-01-05 Proximity Probe No Armor

Description

Bently Nevada 3300 NSv Proximity Probe: Advanced Machine Monitoring Solution

PRODUCT OVERVIEW

New original Bently Nevada 330903-00-05-05-01-05 proximity probe with full factory warranty. Features 50mm case length and enhanced performance for critical industrial applications.

FULL SUFFIX BREAKDOWN

• 330903 – Base model: 3300 NSv Probe, M8X1 thread
• 00 – Unthreaded length: 00 mm
• 05 – Case length: 50 mm
• 05 – Cable length: 0.5 meter
• 01 – Connector: ClickLoc with protector
• 05 – Approvals: Multiple agency certifications

TECHNICAL SPECIFICATIONS

• Electrical Performance
  • Probe resistance: 4.0Ω ±0.5Ω
  • Cable capacitance: 69.9 pF/m
  • Frequency response: 0-10 kHz (±3dB)
• Mechanical Design
  • Case material: AISI 304 stainless steel
  • Tip material: Chemical-resistant PPS
  • Bend radius: 25.4 mm minimum
• Environmental Ratings
  • Operating temp: -52°C to +177°C
  • Sealing: Viton O-ring differential pressure seal
• Measurement Performance
  • Scale factor tolerance: +12.5%/-20%
  • Target size: Min 8.9mm, Recommended 13mm
  • Linearity deviation: <±0.06mm

CABLE & WIRING DATA

• Cable type: 75Ω FEP-insulated coaxial
• Conductor resistance: 0.220 Ω/m (center), 0.066 Ω/m (shield)
• Field wiring: 16-24 AWG, max 305 meters
• Connector torque: 0.56 N•m maximum

INSTALLATION GUIDE

• Optimal gap setting: 1.0 mm (40 mils)
• Installation torque: 5.1 N•m (45 in-lb)
• Max thread engagement: 12 mm
• Mounting: Avoid bending near connector

COMPATIBILITY & UPGRADES

Direct replacement for 3300 RAM probes with 30% better chemical resistance. Superior side-view characteristics compared to 190-series probes.

PACKAGE INCLUDES

• 1x 3300 NSv Probe (P/N: 330903-00-05-05-01-05)
• Connector protector cap
• Factory documentation
• 12-month manufacturer warranty
