Description
3300 NSv Proximity Probe (Model: 330908-00-18-05-02-00)
U.S.-manufactured industrial-grade vibration sensor with 1-year warranty, engineered for precision and durability in harsh environments.
Key Specifications
• Thread: 3/8-24 UNF (unarmored) | Case Length: 18 = 1.8 in
• Case Material: AISI304 stainless steel | Tip: Polyphenylene sulfide (PPS)
• Cable: 75 Ω coaxial FEP insulation | Length: 0.5 m (20 in)
• Weight: 14–150 g (0.5–5.3 oz) | Agency Approval: 00 = Not required
Technical Parameters
• Resistance: 4.0 ± 0.5 Ω (0.5 m cable)
• Torque: Max 33.9 N•m (300 in•lb) | Recommended: 11.3 N•m (100 in•lb)
• Thread Engagement: ≤ 0.563 in
• Pressure Seal: Viton O-ring (non-pressure-tested)
Environmental Resilience
• Operational Range: -52°C to +177°C (-62°F to +351°F)
• Storage Range: -52°C to +177°C
• Risk Note: Sustained exposure below -34°C (-30°F) may compromise seal integrity.
Quality Assurance & Support
• Warranty: 12-month coverage against manufacturing defects.
• Contact: sales@ubestplc.com | +86 180 3000 5825
