Bently Nevada 3500/40-01-00 Proximitor Monitor for Machinery Protection

Description

Product Overview

• Bently Nevada 3500/40-01-00 is a Proximitor Monitor for machinery health.
• Part of the trusted 3500 Series platform.
• Designed for precise shaft and position measurement.
• Built for continuous industrial operation.
• Manufactured in the United States.

Product Highlights

• Stable signal processing for critical assets.
• Compact size fits dense control cabinets.
• Simple wiring with internal termination.
• Long service life in standard environments.
• Proven design used worldwide.

Core Technical Data

• Brand: Bently Nevada
• Model: 3500/40-01-00
• Alternate Module: 176449-01
• Product Type: Proximitor Monitor
• Series: 3500 Series
• Input Type: Proximitor sensor signals
• Measurement Range: Suitable for standard shaft displacement
• Frequency Response: Optimized for rotating machinery
• Accuracy: High repeatability and stability
• Resolution: Fine signal resolution for early fault detection
• Linearity: Maintains linear output across range
• Power Requirement: System supplied via 3500 rack
• Environmental Rating: Industrial control room use
• Hazardous Area Approval: Not included

Physical Characteristics

• Main Monitor Size: 241.3 x 24.4 x 241.8 mm
• Main Monitor Weight: 0.91 kg
• I/O Module Size: 241.3 x 24.4 x 99.1 mm
• I/O Module Weight: 0.20 kg

Installation Notes

• Install directly into a 3500 rack.
• No special tools required.
• Ensure correct slot assignment.
• Verify sensor polarity before startup.

Operation and Maintenance

• Supports fast system commissioning.
• No routine calibration needed.
• Easy module replacement reduces downtime.
• Designed for long-term monitoring.

Application Scenarios

• Steam and gas turbines.
• Large compressors.
• Critical pumps.
• Generators and motors.

Packaging and Logistics

• Industrial-grade protective packaging.
• Global shipping via FedEx, UPS, or DHL.
• Carefully packed to avoid transit damage.

Warranty Policy

• 12-month warranty from shipment date.
• Covers manufacturing defects.
• Technical support available during warranty.

Professional FAQ

• How does this monitor improve reliability?
• It provides early warning of shaft movement issues.
• Is this module good for retrofit projects?
• Yes, it fits existing 3500 racks easily.
• What should engineers check before purchase?
• Confirm sensor type and rack compatibility.
• Does the module suit long-term operation?
• Yes, it is built for continuous use.
• Why choose this model over older monitors?
• It offers better stability and easier service.
