Bently Nevada 3500/46M 176449-06 Vibration Monitoring Module

Description

Product Description

• Bently Nevada 3500/46M 176449-06 is a high-density machinery protection and monitoring module.
• It supports vibration, shaft position, and temperature signals.
• The module suits critical rotating equipment protection.
• It delivers fast data processing and stable long-term operation.
• The design fits harsh industrial environments.

Key Value Highlights

• Up to 46 channels reduce rack space and wiring cost.
• Digital filtering improves signal clarity.
• FFT analysis supports early fault detection.
• Industrial protocols simplify system integration.

Technical Specifications

• Brand: Bently Nevada
• Series: 3500 Series
• Model: 3500/46M
• Part Number: 176449-06
• Input channels: Up to 46 mixed signal inputs.
• Vibration range: 0 to 100 mm/s peak.
• Shaft position range: ±5 mm.
• Temperature range: -40°C to +150°C.
• Frequency response: Wide-band for rotating machinery analysis.
• Sensitivity: Optimized for industrial vibration sensors.
• Linearity: High accuracy across full measurement span.
• Resolution: Fine digital resolution for trend analysis.
• Signal processing: Digital filters and FFT diagnostics.
• Communication: Modbus, Ethernet, industrial protocols.
• Power supply: 100–240 VAC, 50/60 Hz.
• Operating temperature: -20°C to +60°C.
• Enclosure rating: NEMA 4X / IP66.
• EMI immunity: Designed for strong electrical noise environments.
• Dimensions: 241.3 × 24.4 × 241.8 mm.
• Weight: 0.91 kg.

Installation Guide

• Install in a standard 3500 rack.
• Ensure correct grounding before power-up.
• Use shielded cables for vibration inputs.
• Follow torque limits on terminal connections.

Commissioning and Maintenance

• Front-access design simplifies setup.
• Hot-swappable design reduces downtime.
• Built-in diagnostics support fast troubleshooting.
• Minimal routine maintenance required.

Compatibility

• Compatible with Bently Nevada 3500 system racks.
• Works with proximity probes, accelerometers, and RTDs.
• Supports integration with DCS and PLC systems.

Certifications and Compliance

• Designed to meet industrial safety standards.
• Suitable for power, oil, gas, and heavy industry.

Typical Applications

• Steam and gas turbines.
• Compressors and pumps.
• Generators and large motors.
• Critical rotating machinery protection systems.

Diagnostic Capabilities

• Early bearing fault detection.
• Misalignment and imbalance analysis.
• Shaft vibration trend monitoring.
• Temperature anomaly alerts.

Packing List

• 3500/46M 176449-06 monitoring module.
• Factory inspection label.
• Protective industrial packaging.

Warranty and Logistics

• 12-month warranty from delivery date.
• Fast worldwide shipping.
• Courier options: FedEx, UPS, DHL.

FAQ

• Is this module suitable for continuous operation?
• Yes. It supports 24/7 industrial monitoring.
• Can it replace older 3500 vibration cards?
• Yes. It fits standard 3500 racks.
• How does FFT help daily maintenance?
• FFT reveals hidden faults before alarms trigger.
• Is field calibration required often?
• No. Digital stability reduces recalibration needs.
• What is a common user experience tip?
• Use trending data, not alarms alone, for decisions.
