Description
Product Overview
- Bently Nevada 3500/92 136180-01 is a communication gateway module.
- Designed for data exchange between monitoring racks and control systems.
- Part of the proven 3500 Series platform.
- Supports Ethernet and serial communication.
- Ideal for plant-wide monitoring integration.
Main Selling Points
- Fast access to all rack values and alarms.
- Multiple protocol support in one module.
- Stable data transfer under heavy load.
- Simple front access and clear LED status.
- Trusted Bently Nevada reliability.
Core Technical Data
- Brand: Bently Nevada
- Model: 3500/92
- Part Number: 136180-01
- Product Type: Communication Gateway Module
- Series: 3500 Series
- Ethernet Speed: 10 Mbps
- Ethernet Standard: IEEE 802.3
- Connector Type: RJ45
- Serial Interfaces: RS232, RS422, RS485
- Max Update Time: Less than 1 second
- Data Timestamp: Yes
- Alarm Status Transfer: Supported
Supported Protocols
- Bently Nevada host protocol over Ethernet.
- Modbus RTU via serial link.
- Modbus TCP over Ethernet.
- Compatible with control and SCADA systems.
Power and Performance
- Typical power use: 5.0 W with RS232 or RS422.
- Typical power use: 5.6 W with RS485.
- Low heat output during operation.
- Stable performance over long runtime.
Status Indicators
- OK LED shows normal operation.
- TX/RX LED shows active communication.
- Front panel view speeds troubleshooting.
Environmental Limits
- Main module operating range: -30°C to +65°C.
- Main module storage range: -40°C to +85°C.
- I/O module operating range: 0°C to +65°C.
- Humidity tolerance up to 95 percent.
- Designed for non-condensing conditions.
Installation and Use
- Slides directly into a 3500 rack.
- No external power wiring needed.
- Ethernet uses standard twisted-pair cable.
- Quick setup with rack software.
Typical Applications
- Power generation monitoring systems.
- Oil and gas machinery protection.
- Plant DCS and PLC integration.
- Centralized condition monitoring rooms.
Packaging, Shipping, and Warranty
- Industrial protective packaging included.
- Worldwide shipping via FedEx, UPS, or DHL.
- 12-month warranty from shipment date.
- Warranty covers hardware defects.
Professional FAQ
- How does this gateway help system integration?
- It links monitoring data directly to control networks.
- Is Ethernet setup complex for new users?
- No, it uses standard TCP/IP settings.
- What should buyers confirm before ordering?
- Check rack type and protocol needs.
- Can it handle large data volumes?
- Yes, it updates all modules within one second.
- Is this module suitable for upgrades?
- Yes, it fits existing 3500 systems easily.
