Bently Nevada 7200 Proximity Standard Mount Probe 21504-00-56-05-02

Description

Bently Nevada 21504-00-56-05-02 Proximity Vibration Probe

Product Overview

Brand: Bently Nevada | Model: 21504-00-56-05-02 | Status: New in Factory Sealed Pack | 12-Month Warranty

High-precision vibration sensor for industrial machinery monitoring. Features 8mm tip and corrosion-resistant design.

Technical Specifications

• Range: 10-80 mils (0.25-2.0 mm)
• Accuracy: ±4% (system-calibrated)
• Output: 200 mV/mil linear signal
• Temp Limits: Probe: -34°C to +177°C | Electronics: -51°C to +100°C
• Power: -17.5V to -26V DC

Complete Suffix Breakdown

21504-00-56-05-02
├── 00: 0mm unthreaded length
├── 56: 5.6in (142mm) case length
├── 05: 0.5m cable (±5in tolerance)
└── 02: Mini male coaxial connector

Installation Notes

• 3/8-24 threaded mounting
• 8mm probe tip clearance required
• No lead armor – route cables carefully

Industry Applications

• Steam Turbines: Blade vibration detection
• HVAC Systems: Fan imbalance monitoring
• Paper Mills: Roller bearing health checks
• Marine Engines: Crankshaft deflection measurement

Frequently Asked Questions

Q: Does this model require field calibration?
A: System calibration is recommended for ±4% accuracy, but pre-calibrated for plug-and-play use.

Q: Can it monitor slow-rotation equipment (<10 RPM)?
A: Yes, the 0-10kHz range covers ultra-low speed applications.

Q: Is the cable replaceable?
A: No, the 0.5m cable is permanently attached to ensure signal integrity.
