Description
Bently Nevada 3300 XL 8mm Vibration Probe – Industrial-Grade Reliability
Precision Vibration Monitoring for Critical Machinery
This Bently Nevada 330101-00-12-10-12-00 probe delivers superior machinery protection with its rugged 8mm design. Featuring patented TipLoc molding for tip durability and CableLoc technology providing 330N pull strength. The FluidLoc cable option prevents oil leakage through cable interiors. Engineered for harsh environments with extended temperature tolerance and Viton® O-ring pressure sealing.
Technical Specifications
- Brand/Model: Bently Nevada 3300 XL
- Full Suffix: 00-12-10-12-00
- Probe Type: 8mm diameter • 3/8-24 UNF thread • No armor
- Range: 2mm (80 mils) linear range
- Output: 7.87 V/mm ±5% (1m system)
- Accuracy: <±0.025mm deviation (1m system)
- Resistance: 7.59Ω ±0.50 (1m cable)
- Temp Range: -52°C to +177°C (Standard)
- Construction: PPS plastic tip • 304 SST body
- Cable: 1m FluidLoc™ with Miniature ClickLoc connector
FAQ
Q: What’s the maximum cable length?
A: 305 meters (1,000 feet) between probe and monitor
Q: Can this handle high-pressure environments?
A: Features Viton® O-ring seal – contact us for pressure testing
Q: Why choose 8mm over smaller probes?
A: Thicker encapsulation provides 3x greater durability
Packaging & Delivery
- Contents: 3300 XL Probe • Mounting hardware
- Warranty: 12 months manufacturer defect coverage
- Shipping: Worldwide via FedEx/UPS/DHL
