Bently Nevada High Temperature Probe | 330301-000-011-20-90-01-00

Description

Bently Nevada 3300 XL HT Probe: Armored Industrial Sensor for Extreme Conditions

Heavy-duty vibration monitoring solution with stainless steel armor and 3/4-16 UNF threads. Built for 350°C environments. Made in USA.

Download product resources:

• Installation & Safety Manual
• Performance Datasheet

Product Configuration

• Part Number: 330301-000-011-20-90-01-00
• Configuration Code:
  • 000 → Unthreaded section: 0″
  • 011 → Body length: 1.1″
  • 20 → Probe cable: 2.0m
  • 90 → Total length: 9.0m
  • 01 → Armored cable
  • 00 → Standard approvals

Technical Specifications

• Temp Range: -34°C to +350°C (-30°F to 662°F)
• Thread Type: 3/4-16 UNF
• Armor Protection: Stainless steel shielded cable
• Accuracy: ±0.078mm linearity
• Response: 0-6,000 Hz (±3dB)
• Range: 4.0mm detection zone
• Resistance: 5.82Ω
• Weight: 234g cable + 132g body
• Min Target: 30.5mm Ø

Shipping & Support

• 12-month performance warranty
• Global delivery: FedEx/UPS/DHL
• Armored cable included
• 24/7 technical support

Technical Questions

• Q: What’s the armor thickness?
  A: Industrial-grade stainless steel protection
• Q: Can I cut the armored cable?
  A: Not recommended – voids warranty
• Q: Thread compatibility?
  A: Standard 3/4-16 UNF industrial
• Q: Vibration limits?
  A: Handles extreme industrial vibration
• Q: Maintenance schedule?
  A: Annual inspection recommended

Core Benefits

Armored Cable
350°C Rating
UNF Threads
±0.078mm
