Description
Bently Nevada 3300 NSv Proximity Probe: 5-Meter Industrial Sensor
Complete Product Identification
- Full Part Number: 330904-08-15-50-11-00
- Model root: 330904 (NSv Probe, M8X1 thread, armored)
- Suffix breakdown:
- -08- : 80mm unthreaded section
- -15- : 150mm total case length
- -50- : 5.0 meter cable (16.4 ft)
- -11- : ClickLoc connector with protector
- -00- : No agency approvals required
Technical Performance
- Measurement range: 1.5mm linear detection
- Accuracy: ±0.06mm deviation
- Output signal: -1V to -13V DC
- Temp range: -52°C to +177°C
- Cable resistance: 5.3Ω ±0.7Ω (5m length)
- Frequency response: 0-10kHz (±3dB)
Installation Guide
- Set gap to 1.0mm (40 mils) from target
- Max torque: 5.1 N•m (finger tight recommended)
- Min bend radius: 25.4mm (1 inch)
- Max thread engagement: 12mm
Key Benefits
- 30% better side-view performance than older probes
- Works with 305m field wiring
- Viton O-ring pressure sealing
- Fully compatible with 3300 RAM systems
Shipping & Support
- Factory sealed packaging
- Global shipping: FedEx, UPS, DHL
- 12-month warranty from shipment date
Professional FAQ
- Q: Chemical resistance compared to RAM probes?
A: 40% better resistance to industrial chemicals - Q: Minimum shaft size for accurate readings?
A: 8.9mm absolute minimum (13mm recommended) - Q: Pressure rating information?
A: Custom testing available – contact engineering - Q: Cable armor specifications?
A: 304 stainless steel braid for crush protection - Q: Replacement for 3300 RAM systems?
A: Direct electrical and mechanical replacement
Download Resources
Get full technical details:
