Bently Nevada Proximity Probe 3300 Nsv 330904-00-10-50-12-00

Description

Bently Nevada Armored 3300 NSv Proximity Probe

Rugged Industrial Sensing Solution

New 330904-00-10-50-12-00 features stainless steel armor and 100mm case length. Includes FluidLoc cable and M8X1 threading. Ships with 12-month warranty.

Part Number Structure

• Full ID: 330904-00-10-50-12-00
• Configuration:
  • -00-: Zero unthreaded length
  • -10-: 100mm long body
  • -50-: 5.0 meter cable
  • -12-: FluidLoc cable with armor
  • -00: No special approvals

Technical Specifications

• Armored protection: Stainless steel
• Resistance: 5.3Ω ±0.7
• Cable length: 5.0 meters
• Range: 0.25-1.75mm
• Accuracy: ±0.06mm

Enhanced Protection Features

• Full stainless steel armor casing
• Chemical-resistant FluidLoc cable
• 1.0 inch minimum bend radius
• Viton O-ring pressure seal
• Extended 100mm body

Installation Guide

• Set gap: 40 mils from target
• Max torque: 5 in-lb
• Min target diameter: 0.5 inches
• Use shielded triad cable

Package Contents

• Factory-sealed armored probe
• ClickLoc connector with protector
• Installation documentation
• 12-month defect coverage

Shipping Information

Fast global delivery via FedEx, UPS, DHL. Tracking provided.

FAQs

Q: What does armored mean?
A: Extra stainless steel protection

Q: Cable length options?
A: This model has 5m cable (suffix -50-)

Q: When use 100mm case?
A: For deep or hard-to-reach mounting points

Q: Difference between -12- and -11-?
A: -12- has armor protection
