Description
Bently Nevada 3300 NSv Reverse Mount Probe with Extended Reach
Core Specifications
- Brand: Bently Nevada
- Full Model: 330907-05-30-70-02-05
- Thread: M10X1 Reverse Mount
- Cable: 7.0 meters (23.0 feet)
- Connector: Standard ClickLoc
- Approvals: Multiple Global Certifications
Suffix Configuration
330907 - Base Model 05 - M10X1 Threads 30 - Standard Configuration 70 - 7.0m Cable Length 02 - Standard Cable 05 - Multiple Agency Approvals
Performance Data
- Electrical Resistance: 5.9Ω ± 0.9 (7m length)
- Signal Output Range: -1 to -13 Vdc
- Temperature Tolerance: -52°C to +177°C
- Pressure Seal: Viton O-ring design
- Mechanical Load: Max 22.6 N•m torque
- Target Gap: Optimal at 1.0mm
- Weight: 14-150g (0.5-5.3oz)
Installation Requirements
- Thread Engagement: Maximum 15mm
- Recommended Torque: 7.5 N•m (66 in•lb)
- Wiring: Shielded triad cable (16-24 AWG)
- Max Distance to Monitor: 305 meters
- Temperature Caution: Avoid below -34°C sustained
Packaging Contents
- Complete probe assembly
- Installation guide
- 12-month warranty documentation
Shipping Methods
FedEx | UPS | DHL international express
Technical Questions
- Q: What applications require 7m cables?
A: Large turbines, compressors, and generators where sensors are distant from monitoring points - Q: How does cable length affect performance?
A: Longer cables have slightly higher resistance (5.9Ω vs 5.3Ω for 5m) but maintain signal integrity up to 305m - Q: Difference between standard and FluidLoc cables?
A: Standard is for general use; FluidLoc adds chemical resistance for wet/oily environments
