Description
Your Probe’s Armor: The Bently Nevada 31000 Housing
Introducing the Bently Nevada 31000 Proximity Probe Housing Assembly, part number 31000-16-10-00-162-00-02. This complete kit includes a ready-to-install 8 mm probe. It defends your critical sensor from water, impacts, and dust. Perfect for tough outdoor and industrial settings. Get reliable machinery protection right out of the box.
Product Configuration Explained
- Basic Information
- Brand: Bently Nevada
- Model Number: 31000-16-10-00-162-00-02
- Product Type: Complete Probe Housing Assembly
- Understanding the Part Number Code
- -16 : Includes a standard 3300 XL 8 mm probe.
- -10 : Provides 1.0 inch of internal probe cable.
- -00 : No standoff adapter is included.
- -162 : Allows for 16.2 inches of probe penetration.
- -00 : Supplied without additional pipe fittings.
- -02 : Features a 3/4-14 NPT mounting thread.
- Durable Build & Materials
- Housing Body: Strong, conductive PPS plastic.
- Internal Parts: Made from AISI 304 stainless steel.
- External Screws: Corrosion-resistant AISI 303 stainless steel.
- Sealing: Uses a reliable Neoprene O-ring.
- Torque Spec: Tighten nut to 29.4 N·m (260 in·lb).
- Performance & Protection
- Temperature Range: -51°C to +105°C.
- Weatherproof Rating: NEMA 4X and IP66 certified.
- Impact Resistance: Tested to withstand 4 Joule impacts.
- Structural Load: Can support over 200 lbs.
- Safe for Hazardous Areas: Meets anti-static CENELEC standards.
- Shipping & Support
- Package Weight: ~1.2 kg.
- Global Shipping: Available via FedEx, UPS, and DHL.
- Warranty: Comes with a 12-month warranty.
- Need Help? Chat with us on WhatsApp for expert advice.
Common Questions Answered
About the Product
Q: What is inside the box when I order this?
A: You receive a fully assembled housing with a pre-installed Bently Nevada 3300 XL 8 mm probe, ready for mounting.
Q: How does this housing protect the probe?
A: Its NEMA 4X/IP66 rating seals out water and dust. The tough PPS body shields against physical knocks and impacts.
Installation & Selection
Q: What is the “probe penetration” of 16.2 inches?
A: This is how far the probe tip can extend from the mounting point into your machine. It is fixed for this model.
Q: Can I adjust the probe position inside the housing?
A: Yes. You can set the probe at any depth up to the maximum 16.2 inches during installation to achieve your required gap.
Purchasing Advice
Q: How do I choose between model 31000-16-… and 31000-28-…?
A> The -16 variant has a standard probe. The -28 variant includes a probe with extra safety certifications for stricter sites.
