Modicon M340 Ethernet Module: Reliable Network Connection
The BMXNOE0100 module connects your Modicon M340 system to Ethernet networks. This TCP/IP module offers fast data exchange and web server functions. Get the full setup guide for your BMXNOE0100 by downloading the manual now.
- Easy installation and configuration steps
- Complete technical specifications and wiring diagrams
- Troubleshooting guide for common network issues
- Safety instructions and maintenance information
Key Features and Benefits
- Brand & Model: Schneider Electric BMXNOE0100
- Product Family: Modicon M340 Automation Platform
- Network Speed: 10/100 Mbit/s auto-sensing Ethernet
- Connection Type: RJ45 port with twisted pair cable
- Web Server: Built-in configurable web pages
- Protocols: Modbus TCP, SNMP, FDR server
- Data Exchange: I/O scanning and global data features
Technical Specifications
- Power Usage: 90 mA at 24V DC from rack
- Operating Temp: 0°C to 60°C (32°F to 140°F)
- Humidity Range: 10% to 95% non-condensing
- IP Rating: IP20 for indoor use
- Weight: 0.2 kg lightweight design
- Memory Card: Includes 16MB flash card
- LED Indicators: 6 status lights for easy monitoring
Shipping and Packaging
- Single Package: 1 module per box
- Box Size: 11.5 x 11.0 x 5.1 cm
- Box Weight: 235 grams
- Bulk Package: 15 modules per case
- Case Size: 40.0 x 30.0 x 15.0 cm
- Case Weight: 3.868 kg
- Shipping: FedEx, UPS, DHL available
- Warranty: 12 months quality guarantee
Common Questions
- What comes in the box?
- You get the module and a 16MB flash card.
- Does it work with Modbus TCP?
- Yes, it supports Modbus TCP messaging.
- What web server does it have?
- It includes a standard configurable web server.
- How many LED lights does it have?
- There are 6 status LEDs for monitoring.
- What is the power requirement?
- It uses 90 mA at 24V DC from the rack.
