Allen-Bradley 1756-OA16 ControlLogix AC Output Module
Control high-power devices with the Allen-Bradley 1756-OA16. This ControlLogix AC output module offers 16 channels for robust industrial control. It works with 74-265V AC systems and includes mechanical fusing for safety. Install it in any ControlLogix chassis for local or remote applications.
Get the full manual here: 1756 ControlLogix IO Modules Specifications.pdf
Key Features
- Brand: Allen-Bradley
- Series: ControlLogix
- Model: 1756-OA16
- Output Type: 16-Channel AC
- Voltage Range: 74-265V AC
- Mechanically Fused Outputs
- Works in Local or Remote Chassis
Technical Specifications
- Output Current: 0.5A per point
- Total Module Current: 4A @ 60°C
- Operating Voltage: 74-265V AC
- Frequency: 47-63 Hz
- Backplane Current: 400mA @ 5V DC, 2mA @ 24V DC
- Power Dissipation: 6.5 Watts maximum
- Isolation Voltage: 50V continuous
- Response Time: 9.3ms (ON), 11ms (OFF)
- Operating Temperature: 0 to 60°C (32 to 140°F)
- Terminal Blocks: 1756-TBSH, 1756-TBNH
What’s Included
- One (1) Allen-Bradley 1756-OA16 Output Module
Shipping Info
- We ship worldwide using FedEx, UPS, and DHL
- Fast delivery options available
Warranty
- 12-month quality guarantee
- Coverage for defects and malfunctions
FAQ
- What voltage does this module support?
It works with 74-265V AC systems at 47-63 Hz. - How many output points does it have?
It provides 16 individually fused output channels. - Can I use this module for motor control?
Yes, it can control contactors and starters up to 0.5A. - What terminal blocks are compatible?
Use 1756-TBSH or 1756-TBNH removable terminal blocks. - Does it work with remote chassis?
Yes, it works in both local and remote ControlLogix chassis.
