Leuze M12 Connection Cable: Reliable Sensor & Actuator Link
This Leuze K-D M12A-3P-2m-PVC cable ensures a stable connection. It links sensors, switches, and devices in your control system. Perfect for factory automation and packaging lines. Durable PVC cable protects against wear and tear.
Product Code Breakdown: K-D M12A-3P-2m-PVC
- K-D: Connection cable with molded connector.
- M12A: M12 connector, axial (straight) type.
- 3P: 3 pins for signal and power.
- 2m: Cable length is 2.0 meters.
- PVC: Cable jacket material is PVC.
Complete Product Specifications
- Brand & Model: Leuze K-D M12A-3P-2m-PVC
- Cable Type: PVC jacket, black color, 0.34mm² conductor cross-section.
- Electrical Ratings:
- Operating Voltage: ≤ 250V AC/DC for 3/4-pin configuration.
- Current Rating: ≤ 4 Amperes per contact.
- Insulation Grade: Category per IEC 60664-1.
- Connector Details:
- Type: M12, Axial (straight).
- Pin Count: 3 Pins.
- Lock: Screw fitting, self-locking. Nickel-plated zinc diecast housing.
- Torque: Recommended tightening torque 0.6 Nm.
- Mechanical & Environmental:
- Cable Diameter: 4.7 mm to 5.7 mm.
- Minimum Bending Radius: 5 x cable diameter.
- Operating Temperature: -5°C to +70°C (standard PVC range).
- Flexibility: Suitable for fixed installation and light drag chain use.
- Quality & Support:
- Condition: New & Original.
- Warranty: 12 Months from date of shipment.
- Shipping: Fast global delivery via FedEx, UPS, or DHL.
Frequently Asked Questions
- Can I use this 3-pin cable for a 4-pin device?
- No. The pin count must match. This cable has 3 pins. It will only connect to devices with a 3-pin M12 female socket.
- Is the cable oil-resistant?
- The PVC jacket offers good resistance to common oils and coolants. For constant oil immersion, a PUR jacket may be better.
- What is the purpose of the self-locking screw mechanism?
- It prevents the connector from loosening due to machine vibration. This ensures a stable signal and power connection over time.
- Can I cut and re-terminate this cable?
- No. This is a factory-molded cable. The connector is sealed to the cable. For custom lengths, order a pre-made cable or use a field-wireable connector.
- My application has frequent flexing. Is this cable suitable?
- For fixed installation or occasional movement, yes. For continuous flexing in a cable carrier, choose a cable specifically rated for high-flex applications.
