Centum VP Series Yokogawa AAI841-S00 Analog Input Output Module

Description

Yokogawa AAI841-S00 Analog I/O Module

Brand: Yokogawa
Model: AAI841-S00
Type: Analog Input Output Module
System: Yokogawa Centum VP

AAI841-S00 is built for simple and stable 4-20mA signal control.
It does not support HART.
It is a cost-effective choice for basic process control.

Configuration Breakdown (Tree View)

AAI841-S00
│
├─ AAI841   →  Main Hardware
│            ├─ 8 Analog Inputs
│            ├─ 8 Analog Outputs
│            ├─ 4-20mA signal only
│            └─ Non-isolated design
│
├─ -S       →  Standard type
│            └─ No HART function
│
└─ -00      →  Basic version
             └─ Default factory setup

Main Functions

• 8 input channels
• 8 output channels
• 4-20mA loop support
• Common ground structure
• Compact size

Electrical Performance

• Accuracy: ±0.1% FS
• Resolution: 12-bit
• Signal update time: 10–250 ms
• Input impedance: 250 Ω
• Max output load: 550 Ω
• Linearity error: ≤ 0.05%
• Repeat accuracy: ≤ 0.05%
• Zero drift: ≤ 0.02% per °C
• Power supply: 24 VDC ±10%
• Current draw: ≤ 0.6 A

Environmental Data

• Working temp: -40°C to 70°C
• Storage temp: -40°C to 85°C
• Humidity: 5–95% RH
• Shock resistance: 10 G
• Vibration range: 5–100 Hz

Mechanical Details

• Size: 107.5 × 94 × 32.8 mm
• Weight: 300 g
• DIN rail mounting
• Easy wiring terminal

Product Advantages

• Simple design
• Stable current loop control
• Fast response
• Low signal loss
• Long service life
• Low heat output
• Easy system match

Typical Applications

• Flow transmitter signal
• Pressure loop control
• Tank level system
• Valve drive signal
• Motor speed feedback

Warranty & Delivery

• 12 months warranty
• 100% tested before shipment
• Safe export packing
• Ship by FedEx, UPS, DHL

Professional FAQ

• When should I choose non-isolated design?

Choose it when all field devices share same ground.
It lowers cost.
Do not use in high noise area.

• How do I check load compatibility?

Check output loop resistance.
Make sure total load is below 550 Ω.
Add margin for cable length.

• Is this module good for small plants?

Yes.
It is compact.
It fits simple control loops.
Good for water and utility systems.

• What should I confirm before replacement?

Check model code.
Check wiring layout.
Confirm power rating.
Verify channel count.

• How to reduce signal error?

Use shielded cable.
Keep cable short.
Avoid running near power line.
Check grounding point.
