GE Fanuc IC693MDL645 Series 90-30 Digital Input Module
16-channel DC input module for industrial automation. Interfaces with pushbuttons, limit switches, and sensors. Features positive/negative logic and LED status indicators for easy troubleshooting.
Technical Data
- Brand: GE Fanuc
- Model: IC693MDL645
- Series: Series 90-30
- Input Voltage: 0-30VDC (Nominal 24VDC)
- Input Current: 7 mA per point
- Channels: 16 isolated points
- Response Time: 7 ms ON/OFF
- Power Consumption: 80mA @5VDC, 125mA @24VDC
- Connector: 20-screw terminal block (included)
- LED Indicators: 16 (1 per channel)
Discontinuation Notice
This product is DISCONTINUED by manufacturer. We sell remaining new old stock. Check compatibility before ordering.
Installation Guide
- Fits Series 90-30 5-slot or 10-slot baseplates
- Single-slot width module
- Terminal block wiring: 20 screws (included)
- Backplane power: 5VDC/24VDC isolated
Diagnostics & Maintenance
- Channel status: LED indicators for live monitoring
- Troubleshooting tip: Check voltage >11.5VDC for ON state
- Field-logic isolation: 1500V rating
Packaging Includes
- IC693MDL645 module unit
Shipping Options
Global delivery via: FedEx • UPS • DHL
Industry Applications
- ???? Manufacturing: Machine control systems
- ⚡ Energy: Equipment status monitoring
- ???? Packaging: Conveyor sensor interfaces
- ????️ Material Handling: Limit switch integration
FAQ: Common Solutions
- Q: Why won’t my input activate?
A: Verify field voltage >11.5VDC and wiring to common terminal - Q: LED off but voltage present?
A: Check for damaged channel or backplane power - Q: Compatible with 12VDC sensors?
A: Yes, if voltage stays >11.5VDC during operation
0.0 Average Rating Rated (0 Reviews)
