GE Fanuc IC693MCM001 Digital Servo Interface Module
Product Overview
High-performance Digital Servo Interface Module for GE Series 90-30 PLC systems. Features 2ms servo loop updates and functions as a Power Mate J Interface. Made for precision motion control in industrial automation.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | GE Intelligent Platforms |
| Part Number | IC693MCM001 |
| Compatible Series | Series 90-30 PLC |
| Input Channels | 16 digital inputs |
| Update Speed | 2ms servo loop |
| Processing Time | <5 seconds per block |
| Memory Type | Non-volatile flash |
| Weight | 3.00 lbs (1.36 kg) |
| Compliance | EN 61000-4-2 |
Key Features
- Real-time control with 2ms updates
- Seamless integration with Power Mate J systems
- Non-volatile memory protects programs
- 16-point digital input capacity
- Industrial-grade shock/vibration resistance
Installation Guide
- Mount in metal enclosure (EN 61000-4-2 compliant)
- Use shielded cables for all connections
- Maintain minimum 2-inch clearance around module
- Ground chassis directly to cabinet
Diagnostics & Maintenance
- Monitor servo loop timing monthly
- Check input signal quality quarterly
- Verify memory backup annually
- Inspect connectors for corrosion
Package Contents
- IC693MCM001 Interface Module
- Mounting hardware
- Installation guide
Shipping Options
FedEx Express | UPS Worldwide | DHL Priority
Industry Applications
- Automated manufacturing lines
- Robotic assembly systems
- Precision CNC machinery
- Packaging equipment
- Material handling systems
Frequently Asked Questions
Q: What PLC systems is this compatible with?
A: Designed for Series 90-30 PLC systems
Q: Can it control multiple axes?
A: Supports 2-axis servo control simultaneously
Q: Is firmware included?
A: Requires separate IC693 CPU v3.52+ firmware
Q: What’s the operating voltage range?
A: 24V DC nominal (18-32V DC range)
Q: How many programs can it store?
A: Holds 10 programs + 40 subroutines
