Description
Schneider Electric 140DAO84210 AC Output Module
16-channel module for industrial control systems. 12-month warranty. Ships worldwide.
Essential Features
- Controls 16 devices at once
- Works with 83-253V AC power
- Quick response: 0.5 ms switching
- Handles power surges up to 30A
- Built-in safety fuses
Technical Specifications
- Voltage Range: 83-253V AC
- Max Load: 2.5 mA leakage (230V)
- Surge Protection: 30A for 1 cycle
- Power Use: 350 mA bus current
- Weight: 0.45 kg (1 lb)
Status Indicators
- Green ACTIVE light (bus communication)
- Red FAULT light (problems detected)
- 16 green lights (output status)
Environmental Ratings
- Temp Range: 0°C to 60°C (32°F to 140°F)
- Works at 95% humidity
- Handles 5000m altitude
- Shock protection: 4-8kV
Installation Guide
- Group outputs in sets of 4
- Use 47-63Hz power supply
- Max voltage drop: 1.5V
- Check all status lights after install
Shipping Details
- Packaged size: 16.3 x 4.5 x 31.2 cm
- Package weight: 634 g
- Fast shipping: FedEx • UPS • DHL
- Origin: China
Common Questions
Q: How many devices can it control?
A: Up to 16 separate devices
Q: What voltage does it need?
A: Works with 83-253V AC systems
Q: How fast does it respond?
A: Turns on/off in 0.5 milliseconds
Q: Is it safe for wet areas?
A: No – for dry locations only (IP20)
Q: What if a fuse blows?
A: Red FAULT light will turn on
