FANUC A06B-6066-H246 Dual-Axis Servo Drive
The A06B-6066-H246 is a powerful AC servo amplifier from FANUC. It is built for precision CNC machines. This drive controls two motor axes at once. It offers position, speed, and torque control for flexible operation.
Core Benefits
- Controls Two Axes: Run two servo motors from one compact unit.
- Triple Control Modes: Switch between position, speed, or torque control.
- Wide Voltage Range: Works with 200V, 220V, and 230V AC input.
- Built-in Protection: Guards against overloads, overcurrent, and overvoltage.
- Efficient Air Cooling: Fan-cooled design for reliable continuous operation.
- Easy Installation: Can be mounted vertically or on a wall to save panel space.
- Factory New: Original FANUC quality with full warranty support.
Complete Technical Data
Identification & Physical
- Brand: FANUC
- Model Number: A06B-6066-H246
- Product Series: A06B
- Product Type: AC Servo Amplifier (Drive Unit)
- Unit Weight: 15.0 pounds (approximately 6.8 kilograms)
- Primary Application: CNC Machine Tools and Automation Systems
Electrical Specifications
- Number of Axes: 2
- Input Power Supply: Single-Phase AC
- Rated Input Voltage: 200 / 220 / 230 Volts AC
- Voltage Tolerance: +10% / -15%
- Input Frequency: 50 Hz or 60 Hz
- Control Functions: Position Control, Speed Control, Torque Control
Environmental & Mechanical
- Operating Temperature: 0 degrees Celsius to 55 degrees Celsius
- Cooling Method: Forced air cooling (internal fan)
- Preferred Mounting: Vertical orientation or wall mounting
- Protection Features: Overload protection, Overcurrent cutoff, Overvoltage protection
- Communication Interface: Designed for FANUC CNC and servo networks
Full Warranty & Global Shipping
We provide a solid 12-month warranty on this FANUC servo drive. Your order ships quickly via FedEx, UPS, or DHL. You will receive a tracking number as soon as the unit leaves our warehouse.
Where to Use This Drive
- CNC Milling Machines and Machining Centers
- CNC Lathes and Turning Centers
- Industrial Robotics and Automation Cells
- Precision Grinding Machines
- Material Handling and Indexing Systems
Professional FAQs for the A06B-6066-H246
Q: Can I use this drive to replace a single-axis amplifier?
A: Yes, but it controls two axes. You can use one axis now and leave the other for future expansion, or just use one channel.
Q: What FANUC motors are compatible with this amplifier?
A: It is designed to work with FANUC AC servo motors from the same generation. You must check the motor series and power rating for a correct match.
Q: Does it come with the necessary connection cables?
A: No. The drive unit is supplied alone. You need to purchase the power, feedback, and control cables separately based on your system layout.
Q: How do I handle an alarm or fault code on the display?
A>First, note the alarm number. Refer to the FANUC maintenance manual. Common causes are wiring issues, overload, or a problem with the connected motor.
Q: Is parameter setup difficult for a new machine?
A>Initial setup requires a FANUC parameter list for your specific machine and motors. This is typically done by a qualified technician using the system’s interface.
