Description
Product Description
- The Flexem FC5-30MR-AC is a compact basic logic controller.
- It is perfect for industrial machine control and automation tasks.
- This unit combines 30 total I/O points in one device.
- You get 18 digital inputs and 12 relay outputs built-in.
- It runs on a standard 220V AC power supply.
- Strong communication includes two serial ports and one Ethernet port.
- Add one expansion board for more I/O flexibility.
- Setup is simple with the USB Type-C programming port.
Technical Specifications
- Brand & Model: Flexem FC5-30MR-AC
- Series Type: FC5 Basic Logic Control
- Power Supply: 220V AC
- Total Built-in I/O: 30 Points
- Input Points (Digital): 18
- Output Points (Relay): 12
- High-Speed Pulse I/O: Not Supported
- Expansion: Supports 1 expansion board & multiple I/O modules
- Communication Ports:
- Serial Port 1: RS485/232 (DB9 connector)
- Serial Port 2: RS485 (Terminal block)
- Ethernet: 1 x RJ45, 10/100M adaptive
- Programming: USB Type-C
- Modbus Channels: 2 (via serial ports)
- Baud Rate Range: 4800 to 115200 bps
- Real-Time Clock (RTC): Built-in with battery backup
- RTC Accuracy: ±3 seconds per day
- Backup Battery Life: ~1 year after power loss
- Operating Temperature: 0°C to 55°C (32°F to 131°F)
- Storage Temperature: -20°C to 70°C (-4°F to 158°F)
- Humidity Range: 10% to 90% non-condensing
- Vibration/Shock Resistance: Designed for industrial environments
- Noise Immunity: High level of anti-interference
Easy Installation & Setup
- Mounts on a standard DIN rail quickly.
- Clear terminal markings for easy wiring.
- USB Type-C port allows fast connection for programming.
Convenient Debugging & Maintenance
- Monitor logic and status in real-time via software.
- Update controller firmware easily through USB.
- Modular design allows for quick part replacement if needed.
Strong Compatibility
- Works with Flexem brand expansion modules.
- Communicates using standard Modbus RTU and TCP protocols.
- Compatible with most common industrial sensors and devices.
Certifications & Standards
- CE marked for safety and EMC.
- Complies with RoHS environmental standards.
What’s in the Box?
- 1 x Flexem FC5-30MR-AC PLC Unit
- 1 x User Manual
- DIN rail mounting clip
Warranty & Support
- 12-month warranty against manufacturing defects.
- Contact our technical support for assistance.
Fast Global Shipping
- We ship worldwide via FedEx, UPS, and DHL.
- You will receive tracking information after dispatch.
Where is it Used?
- Controlling packaging machines and conveyors.
- Automating small production lines.
- Building management systems for lighting and HVAC.
- Simple process control in water treatment.
Built-in Diagnostic Features
- LED status lights for power, run mode, and errors.
- I/O status can be viewed and monitored from software.
- Communication port activity indicators.
Frequently Asked Questions
Q: What is the main advantage of this PLC model?
A: Its main strength is combining 30 I/O points with strong communication (serial and Ethernet) in a compact, cost-effective unit.
Q: Can I connect a touchscreen HMI to it?
A: Yes, you can connect an HMI using the RS485 port or the Ethernet port with Modbus protocol.
Q: Is the built-in battery for the clock replaceable?
A> Typically, the RTC battery is internal and not user-replaceable. Its long life minimizes this concern.
Q: How do I start programming this controller?
A: Download the free programming software from Flexem, connect via the USB-C cable, and you can begin writing logic.
Q: What happens if I need more than 12 relay outputs?
A: You can add a digital output expansion module through the supported expansion board to increase your output count.
Q: Can it communicate with other brands of devices?
A> Absolutely. The standard Modbus support allows it to talk to thousands of different sensors, drives, and other PLCs.
Q: Is it suitable for a very dusty factory environment?
A: It has a good industrial-grade construction, but for extremely harsh conditions, consider installing it in a protected cabinet.
Q: From experience, what’s a common setup mistake?
A: Ensure the power supply is stable 220V AC and that communication wiring (especially RS485) uses correct polarity and termination.
