Description
Product Introduction
The Flexem FL8-E4-D is a powerful 4-core motion control CPU module. It combines a PLC with advanced motion control. This compact unit has built-in EtherCAT for high-speed, precise multi-axis control. It supports 4 EtherCAT axes plus pulse axis control. Integrated 8 digital inputs and 8 NPN outputs simplify your setup. Two Ethernet ports offer flexible networking. Its expandable design grows with your application needs. Perfect for demanding automation tasks.
Technical Specifications
- Brand & Model: Flexem FL8-E4-D CPU Module
- Core Processor: 4-core, 1GHz CPU
- Memory: 1GB RAM, 4GB Storage
- Motion Control: 4-axis EtherCAT + 6 pulse outputs (200KHz)
- Integrated I/O: 8 DI (NPN/PNP), 8 DO (NPN)
- High-Speed Inputs: 7 x 200KHz pulse inputs
- Connectivity: 2x Ethernet (100M), 1x EtherCAT Master Port
- Expansion: Left-side (4G/WiFi/Serial) & Right-side (max 31 modules)
- Programming: Supports IL, LD, ST, SFC, CFC, FBD
- Data Capacity: Program: 32MB, User Data: 128MB
- Communication Ports: 2x RS485, 1x CAN, USB Type-C
- Supported Protocols: EtherCAT, Modbus-TCP/RTU, CANopen, OPC UA
- Power Supply: DC24V ±20%
- Frequency Response: 200KHz for pulse signals
- Operating Temperature: 0°C to 55°C
- Environmental Rating: Industrial grade, high vibration resistance
- EMC Immunity: High noise immunity for stable operation
Easy Installation
- Mount on standard DIN rail (35mm).
- Connect 24V DC power with correct polarity.
- Use shielded cables for EtherCAT and signal lines.
- Ensure proper earthing for safety and performance.
Simple Setup & Maintenance
- Program via USB Type-C or Ethernet.
- Online monitoring helps quick diagnostics.
- Modular design allows easy part replacement.
- Firmware updates via USB drive.
Wide Compatibility
- Works with major servo drives and VFDs.
- Connects to HMI, SCADA, and ERP systems.
- Supports standard industrial fieldbuses.
- Expands with various I/O and special function modules.
Certifications & Warranty
- CE certified for European market.
- RoHS compliant for environmental safety.
- 12-month manufacturer warranty included.
- Worldwide shipping via FedEx, UPS, DHL.
Package Includes
- Flexem FL8-E4-D CPU Module x1
- Quick Start Guide x1
- Mounting accessories kit
Where to Use It
- Robotic cell and arm control
- Packaging and palletizing machines
- CNC and automated assembly systems
- Printing, textile, and material handling
Built-in Diagnostics
- Real-time I/O status monitoring
- Network connection health check
- Error code logging for troubleshooting
- Power and temperature status alerts
Frequently Asked Questions
What is the main advantage of this module?
It combines a full-featured PLC with powerful multi-axis motion control in one compact unit.
How many axes can I control in total?
You can control 4 axes via EtherCAT and additional axes using the high-speed pulse outputs.
Can beginners program this controller?
Yes. The support for Ladder Diagram (LD) makes it accessible for technicians new to programming.
What if I need more digital inputs later?
Simply add standard I/O expansion modules to the right side of the CPU. It supports up to 31 modules.
How reliable is it in a noisy factory?
Very reliable. It has industrial-grade EMC protection. Always use the recommended shielded cables for communication.
Is training available for this product?
Yes. We provide detailed manuals and online tutorial videos. Contact our support for specific training inquiries.
From experience, what is the first thing to check if communication fails?
First, verify the network cable connection and the IP address settings. Then, check the status LEDs on the EtherCAT port.
Any tip for faster project startup?
Use the pre-built function blocks for common tasks like homing and gear coupling. This saves significant development time.
