Description
Product Description
- Flexem FR-D0016N is a compact 16-channel digital output module.
- It provides NPN transistor outputs for stable control.
- The design suits industrial automation and PLC expansion.
- LED indicators display each channel status clearly.
- DIN-rail mounting improves cabinet efficiency.
Technical Specifications
- Brand: Flexem
- Model: FR-D0016N
- Series: FR Digital Output Series
- Module Type: Digital Output Module
- Output Channels: 16 points
- Output Logic: NPN switching
- Single Channel Current: Max 1000 mA
- Total Output Current: Max 500 mA
- Frequency Response: Up to 1 kHz
- Resolution: Digital on or off
- Linearity: Discrete logic output
- Sensitivity: PLC control signal level
- Operating Temperature: -20°C to +60°C
- Storage Temperature: -40°C to +85°C
- Humidity Range: 5% to 95% non-condensing
- EMC Performance: High noise immunity
- Anti-Interference: Industrial-grade isolation
- Status Indicator: 16 LED indicators
- Mounting: 35 mm DIN rail
- Dimensions: 111 mm × 18 mm × 76 mm
- Weight: Approx. 65 g
Installation Guide
- Install directly onto a standard 35 mm DIN rail.
- Confirm correct grounding before powering on.
- Allow ventilation space inside the control cabinet.
- Use labeled terminals to simplify wiring.
Commissioning and Maintenance
- LED lights support fast output testing.
- No calibration is required during setup.
- Modular design enables quick replacement.
- Routine checks extend operating life.
Compatibility
- Compatible with Flexem PLC controllers.
- Works with common industrial power supplies.
- Supports relays, solenoids, and actuators.
- Fits standard automation enclosures.
Certifications and Compliance
- Designed according to industrial safety standards.
- Complies with CE and EMC directives.
- RoHS compliant materials used.
Typical Applications
- PLC output expansion systems.
- Factory automation control panels.
- Packaging and conveying equipment.
- Building and energy automation systems.
Diagnostic Capability
- Visual LED status simplifies fault finding.
- Fast detection of wiring or load issues.
- Improves maintenance efficiency.
Package Contents
- 1 × Flexem FR-D0016N digital output module
- Quick installation guide
- Protective factory packaging
Warranty and Shipping
- 12-month warranty from delivery date.
- Worldwide shipping via FedEx, UPS, or DHL.
- Secure packaging for international delivery.
FAQ
- Can the module drive industrial relays?
- Yes, within the rated output current.
- Is it reliable in noisy environments?
- Yes, it resists electrical interference well.
- How do technicians verify output status?
- They observe the LED indicators.
- What helps long-term stable operation?
- Correct wiring and proper grounding.
