Description
Product Overview
The Flexem FR-D0808N is a compact digital mixed I/O module for industrial automation.
It combines stable inputs and high-current transistor outputs in one slim unit.
This module supports both NPN and PNP signals for flexible system design.
It fits control cabinets with limited space and high reliability needs.
Core Advantages
- 8-point digital inputs with bidirectional signal support
- 8-point NPN transistor outputs with strong load capacity
- 24VDC rated voltage for standard control systems
- Slim 18 mm width for dense installations
- Low power consumption and stable signal detection
Technical Specifications
- Brand: Flexem
- Model: FR-D0808N
- Module Type: Digital Mixed Input and Output Module
- Input Channels: 8-point, NPN and PNP compatible
- Rated Input Voltage: 24VDC
- Input Voltage Range: 0 to 28.8VDC
- Input Current: 7 mA per channel
- Output Channels: 8-point NPN transistor
- Rated Output Voltage: 24VDC
- Output Voltage Range: 19.2 to 28.8VDC
- Output Current: 0.5 A per channel
- Current Per Group: 0.5 A multiplied by active outputs
- Response Speed: Suitable for high-speed digital control
- Noise Immunity: Designed for industrial EMI environments
- Operating Temperature: Stable in standard control cabinet ranges
- Protection: Short-circuit and overload tolerant design
- Dimensions: 111 × 18 × 76 mm
- Weight: 65 g
Installation Guide
- Mount securely on DIN rail or control panel
- Confirm 24VDC power before wiring inputs
- Separate signal and power cables when possible
- Ensure proper grounding for noise reduction
Commissioning and Maintenance
- LED indicators support quick status checks
- No special software needed for basic testing
- Modular wiring simplifies replacement
- Routine inspection ensures long service life
Compatibility
- Works with Flexem PLC and HMI systems
- Compatible with standard 24VDC sensors
- Supports proximity switches and limit switches
- Integrates with relay and solenoid loads
Certifications and Quality
- Manufactured under strict industrial quality control
- Designed for continuous factory operation
- Meets common automation safety standards
Typical Applications
- PLC-based machine control
- Packaging and assembly lines
- Material handling systems
- Building and factory automation
Diagnostic Capabilities
- Clear channel status via onboard LEDs
- Fast fault identification during startup
- Helps reduce downtime and service costs
Packing and Warranty
- 1 × Flexem FR-D0808N digital I/O module
- Factory protective packaging
- 12-month warranty
- Shipping via FedEx, UPS, or DHL
FAQ
- Can this module work with both NPN and PNP sensors?
- Yes. The input design supports both wiring types without hardware changes.
- Is the output suitable for driving solenoid valves?
- Yes. Each output supports up to 0.5A for industrial loads.
- How does this module perform in noisy environments?
- Proper grounding ensures stable signals even near motors.
- What is a common installation mistake?
- Mixing signal and power cables often causes false triggers.
