Foxboro FCP270 P0917YZ Field Control Processor

Description

Overview

The Field Control Processor FCP270 is a highly reliable distributed controller designed to handle process control, alarming, and automation functions across various industrial environments. With a wide range of features, the FCP270 ensures high performance and operational flexibility, making it an essential component in process automation and control applications.

Environmental Specifications:

• Operating Temperature: 0 to +60°C (+32 to +140°F)
• Relative Humidity: 5 to 95% (Non-condensing)
• Altitude: -300 to +3,000 m (-1,000 to +10,000 ft)
• Vibration: 0.5 g (5 to 500 Hz)

Physical Specifications:

• Configuration: Single processor module with the option of a fault-tolerant version featuring two processor modules.
• Mounting Options: Can be mounted on 2- or 4-position baseplates, designed for both horizontal or vertical installations.
• Dimensions:
  • Height: 103 mm (4.04 in) to 114 mm (4.50 in) (including mounting lugs)
  • Width: 51.5 mm (2.03 in)
  • Depth: 147 mm (5.80 in)
• Mass: 0.6 kg (1.3 lb) for a single non-fault-tolerant module.

Fiber Optic Cabling:

• Connectors:
  • Ethernet Switch Connector: One MT-RJ connector.
  • FCP270 Connector: Two ceramic-type LC connectors with clips.
• Cable Material: Multimode fiber (MMF), 62.5/125 µm plenum-rated.
• Cable Lengths: Available in 3 m (9.9 ft), 15 m (49.5 ft), and 50 m (165 ft), with user-supplied lengths greater than 50 m.
• Maximum Cable Length: 2 km (6,560 ft) from the Ethernet switch to the FCP270.
