Meet the FPad716: Your Smart Industrial Display
The Flexem FPad716 is a next-generation IoT HMI. It delivers sharp, high-definition video playback. This unit ensures fast and reliable communication for your machines. It fits a wide variety of industrial applications perfectly.
Why Choose the FPad716?
- Crystal Clear 15.6″ Display: Full HD 1080p resolution for excellent detail.
- Powerful 4-Core Processor: Handles complex tasks smoothly and quickly.
- Rich Connectivity: Dual Gigabit Ethernet, USB 3.0, and multiple serial ports.
- Built Tough for Industry: IP65 front panel protects against dust and water.
- Flexible Communication: Optional WiFi and 4G for wireless freedom.
- Easy Integration: Runs on a stable Linux operating system.
- Wide Voltage Input: Works reliably from 18V to 28V DC.
Detailed Technical Specifications
Display & Touch
- Screen Size & Type: 15.6-inch TFT LCD with 16:9 aspect ratio
- Resolution: 1920 x 1080 pixels (Full HD)
- Brightness: 250 candelas per square meter
- Viewing Angle: Wide 85 degrees on all sides
- Touch Technology: 4-wire resistive touch (works with gloves)
- Display Colors: 16.7 million (24-bit depth)
Hardware & Performance
- Central Processor (CPU): 64-bit quad-core ARM Cortex-A55 @ 2.0 GHz
- Graphics Processor (GPU): ARM Mali-G52
- Memory (RAM): 2 Gigabytes DDR4
- Internal Storage: 16 Gigabytes eMMC
- Real-Time Clock (RTC): Built-in for timekeeping
- Audio Output: Integrated horn/speaker
Connectivity Ports
- Ethernet: Two (2) ports, 10/100/1000 Mbps speed
- USB: Two (2) USB 3.0 Type-A ports on rear panel
- Video Out: One (1) HDMI 2.0a port (supports 1080p)
- Serial Port 1 (COM1): Configurable as RS-232, RS-485, or RS-422
- Serial Port 2 (COM2): Configurable as RS-485 or RS-422
- Serial Port 3 (COM3): RS-232 standard
- Wireless Options: WiFi module and 4G/LTE module (optional add-ons)
Power & Environmental
- Power Supply: 24V DC nominal (18V to 28V range)
- Power Consumption: Typically less than 18 Watts
- Power Protection: Isolated adapter with surge protection
- Operating Temperature: -10°C to +60°C
- Storage Temperature: -20°C to +70°C
- Ambient Humidity: 10% to 90% (non-condensing)
- Front Panel Rating: IP65 (dust-tight and protected against water jets)
- Rear Panel Rating: IP20 (finger-safe)
- Vibration Resistance: 2G acceleration in all axes
- Housing Material: Non-ferrous alloy chassis
Physical Dimensions
- Unit Dimensions (HxWxD): 256mm x 394mm x 31mm
- Panel Cutout (HxW): 245mm x 380mm
- Product Weight: Approximately 2.5 kilograms
- Installation: Standard flush mounting
- Cooling Method: Passive natural convection
Warranty & Global Shipping
Every Flexem FPad716 comes with a solid 12-month manufacturer’s warranty. We ship directly to your facility using express carriers: FedEx, UPS, and DHL. You will receive tracking information as soon as your order is dispatched.
Perfect For These Applications
- Factory Machine Operator Interfaces (HMI)
- Industrial IoT Gateways and Data Concentrators
- Digital Signage and Information Kiosks
- Equipment Monitoring and Control Dashboards
- Automated Warehouse Management Systems
- Building Automation and Environmental Control
Expert FAQs for the FPad716
- Q: Can I play video files directly on this HMI?
- A: Yes. The powerful processor and GPU are designed for smooth HD video playback from its internal storage or a network source.
- Q: How do I connect to old PLCs with serial ports?
- A: Use COM1, COM2, or COM3. You can wire them for RS-232, RS-485, or RS-422 to match almost any legacy PLC or device.
- Q: Is the screen readable in bright sunlight?
- A: The standard brightness is 250 nits. For very bright areas, consider an optional high-brightness model if available from Flexem.
- Q: What software is used for creating HMI projects?
- A: Flexem provides dedicated configuration and development software. You design your screens on a Windows PC and then download them to the FPad716.
- Q: My power supply has slight fluctuations. Is that a problem?
- A: No. The FPad716 accepts a wide input range (18V-28V DC) and has built-in protection against surges and short power dips.
