Next-Gen Flexem FPad916R001 IPC with Celeron J3455 and 8GB RAM

Description

Flexem FPad916R001: The Next-Generation IoT HMI

Meet the Flexem FPad916R001. This is a powerful, innovative IoT HMI.
It offers an open-ended programming experience for industrial control.
The unit efficiently handles large data volumes.
It ensures excellent operational performance.
Choose the FPad916R001 for your advanced automation needs.

Core Hardware and Performance

• Processor Power: Intel Celeron J3455. It has 4 cores. Speed starts at 1.50GHz, boosting to 2.30GHz.
• System Memory: 8GB DDR3L RAM. Supports 1333/1600/1866 MHz frequencies.
• Storage Solution: Fast 128GB SATA SSD. This ensures quick boot-up and reliable data access.
• Software Environment: Runs on a stable Linux operating system. Program using FStudio Unified software.

Visual Excellence and Touch Interface

• Display Size: Large 15.6” TFT LCD (16:9 aspect ratio).
• High Resolution: Crisp 1920×1080 Full HD display.
• Color Depth: Vibrant 24-bit color representation.
• Brightness and Life: 250cd/m² brightness. LCD lifetime is 50000 hours.
• Touch Technology: Reliable 4-wire industrial resistance touch screen.

Connectivity and Expansion

• Network Ports: Two RJ45 Ethernet ports (LAN1, LAN2). Both support 10/100/1000 Mbps.
• High-Speed USB: Four USB3.0 ports (Type-A, Rear IO).
• Video Output: Two HDMI display ports. Supports up to 3840×2160 resolution.
• Serial Communication: Three serial ports (COM1, COM2, COM3). Supports RS232/RS485/RS422.
• Wireless Option: WiFi capability is available as an option.

Industrial Durability and Installation

• Protection Level: IP65 front panel protection (with NEMA panel). Back is IP20 rated.
• Operating Temperature: Handles temperatures from -0 to 50˚C.
• Humidity: 10 to 90%RH (non-condensing).
• Vibration Resistance: Withstands 2G vibration (10-25Hz) for 30 minutes.
• Cooling: Uses reliable Natural cooling design.
• Construction: Durable Non-ferrous alloy housing.
• Cutout Dimensions: Precise cutout of 380×245mm is required.

Power, Certification, and Purchase Details

• Input Power: Requires DC12V < 5 A input voltage. Rated power is < 60W.
• Power Safety: Isolated power adapter is included. It has lightning surge protection.
• Certifications: Compliant with CE and RoHS standards.
• Warranty: We provide a full 12-month warranty against defects.
• Shipping: We use fast, reliable carriers: FedEx, UPS, and DHL.

Expert FAQs on the FPad916R001

• What advantage does the Celeron J3455 CPU offer?
  The quad-core processor provides strong performance. This is crucial for running complex visualization and data logging tasks simultaneously.
• How does the dual Ethernet design benefit my application?
  Two LAN ports allow network segmentation. You can separate the control network from the enterprise network for better security and stability.
• Can I use a third-party operating system with this HMI?
  The unit ships with a specific Linux build. While it is possible, using the default OS ensures full hardware compatibility and warranty coverage.
• What is the significance of the 5ms power interruption tolerance?
  This short tolerance means the unit must have stable power. Use an external UPS or quality power supply to avoid sudden shutdowns.
• Is the RS485 converter a separate purchase?
  Yes, achieving additional RS485 communication requires a separate USB to RS485 converter. This offers flexible connectivity options.
