GE Fanuc IC697VAL348: 8-Channel High-Precision Analog Output Board
Need precise analog control for your industrial system? The GE Fanuc IC697VAL348 delivers. This 8-channel D/A converter turns digital commands into stable analog signals. It is perfect for controlling valves, drives, and recorders. Achieve accurate control with 16-bit resolution. Boost your Series 90-70 PLC’s capability today.
Product Highlights
- 8 Isolated Outputs: Control multiple devices from one reliable board.
- High 16-Bit Resolution: Get very precise and smooth analog signals.
- 10V Buffered Voltage Output: Strong signal for driving various loads.
- Robust Industrial Design: Built with a double Eurocard and DIN connector.
- Clear Fault Indication: Front-panel LED alerts you to any issues instantly.
- Flexible Configuration: Factory jumpers let you set up the board for your needs.
Detailed Technical Specifications
- Manufacturer & Model: GE Fanuc (Emerson) IC697VAL348
- Product Series: Series 90-70 I/O Module
- Board Type: 8-Channel Digital-to-Analog Converter (DAC)
- Output Channels: 8 independent, voltage-output channels
- Output Range: 0 to +10 Volts DC
- Output Current: 5 mA per channel (typical)
- Resolution: 16-bit (providing 65,536 discrete output steps)
- Output Accuracy: High linearity, typically within ±0.1% of full scale
- Connector Type: High-reliability industrial DIN connector
- Form Factor: Double-height Eurocard for VMEbus systems
- Board Weight: 3.00 lbs (1.36 kg)
- Diagnostic LED: Yes, front-panel “FAIL” indicator
- Configuration: 6 factory-set jumper blocks (JA, JB, JC, JD, JE, S1/S2)
- Operating Temperature: 0°C to 60°C (standard industrial range)
- Power Requirement: +5V DC from the VMEbus backplane
Package, Warranty & Logistics
- Package Includes: One GE Fanuc IC697VAL348 converter board.
- Quality Warranty: Full 12-month warranty against defects.
- Global Shipping: Fast delivery via FedEx, UPS, or DHL.
Expert Answers to Common Questions
1. What kind of devices can I connect to this board’s outputs?
You can connect to speed controllers, servo drives, analog chart recorders, or process controllers that accept a standard 0-10V control signal.
2. How do I set the correct address for this board in my PLC rack?
Use the base address selection switches (S1 and S2) on the board. Refer to the GE Series 90-70 hardware manual for the correct switch settings based on your desired slot address.
3. One channel shows a fault LED. What should I check first?
First, check the wiring for a short circuit or overload on that channel. Then, verify the digital code and output range settings in your PLC program match the board’s jumper configuration (JA, JB).
4. Can I use this board to output a -10V to +10V signal?
No. The IC697VAL348 is designed for unipolar 0 to +10V output.
5. Is special software needed to program and use this analog output board?
You program it using the standard GE Proficy Machine Edition (PME) software. You configure the digital values in your ladder logic or function block diagrams that correspond to the desired analog voltage.
Ready to Order or Need Technical Advice?
Contact our automation specialists for product details, pricing, and compatibility support for your GE Series 90-70 system.
Email: info@oiltechcontrols.com
Technical Support via WhatsApp: +86 158 8020 0923
