Description
GE IC200MDL241 Discrete Input Module: High-Density AC Input Interface
Core Functionality
16-channel AC input module for VersaMax PLC systems. Designed for sourcing-type devices with positive logic. Receives current from AC input devices and returns through common terminal. Ideal for high-voltage industrial monitoring applications.
Technical Specifications
| Manufacturer | GE Industrial |
| Model | IC200MDL241 |
| Input Channels | 16 (2 groups of 8) |
| Voltage Range | 0-264VAC (47-63Hz) |
| On Threshold | 155-264VAC / 7mA min |
| Off Threshold | 0-40VAC / 1.5mA max |
| Response Time | ON: ≤1 cycle (17ms) OFF: ≤2 cycles (34ms) |
| Isolation Rating | 1500VAC (1 min) 250VAC continuous |
Electrical Characteristics
Input Impedance
38.5kΩ @60Hz
46.3kΩ @50Hz
38.5kΩ @60Hz
46.3kΩ @50Hz
Backplane Power
5VDC @ 110mA max
5VDC @ 110mA max
Group Isolation
250VAC continuous
250VAC continuous
Point-to-Point
No isolation
No isolation
Installation & Diagnostics
- Hot-swappable module for VersaMax racks
- Per-point LEDs show real-time status
- Green OK LED confirms backplane power
- No external power required
Industrial Applications
- Machine status monitoring in manufacturing
- HVAC equipment control systems
- High-voltage pump/compressor feedback
- Production line safety interlocks
Packaging & Support
- Single IC200MDL241 module
- 12-month manufacturer warranty
- Global shipping: FedEx, UPS, DHL
Technical FAQ
Q: Can this module handle DC inputs?
A: No, designed exclusively for 47-63Hz AC signals
Q: What’s the maximum wire gauge supported?
A: Accepts 12-24 AWG wiring terminals
Q: Is group isolation sufficient for phase-separated systems?
A: Yes, 250V continuous isolation between input banks
Q: Can I mix voltage levels in the same group?
A: All inputs in group share common terminal – maintain consistent voltage
