GE IC200MDL243 VersaMax Input Module Isolated

Description

IC200MDL243: 16-Point Isolated AC Input Module

GE Fanuc’s IC200MDL243 delivers 16 fully isolated input points for industrial control systems. Handles AC inputs up to 132V with fast response times. Features per-point status LEDs for instant diagnostics.

Technical Specifications

• Brand: GE Fanuc
• Model: IC200MDL243
• Module ID: 88048804
• Input Points: 16 isolated channels
• Voltage Range: 0-132VAC (47-63Hz)
• Nominal Voltage: 120VAC
• Response Time: 1 cycle ON / 2 cycles OFF max
• Isolation Rating: 1500VAC for 1 minute
• Current Consumption: 100mA max @5V (backplane)
• Input Impedance: 8.6kΩ @60Hz / 10.32kΩ @50Hz

Installation Guide

Mount in Versamax rack. Connect AC devices to isolated terminals. Ensure common wire returns to source. Verify green OK LED illuminates.

Diagnostics & Maintenance

• LED diagnostics: Green point LEDs show active inputs
• No OK light? Check backplane power connection
• Clean terminals annually with contact cleaner
• Keep below 55°C ambient temperature

Packaging List

• IC200MDL243 module (1 unit)
• No documentation or certificates included

Shipping Methods

Express delivery via FedEx, UPS, DHL. Tracking number provided.

Frequently Asked Questions

• Min activation voltage?
• 70VAC required for ON state
• Supported frequencies?
• 47-63Hz AC signals
• Isolation between points?
• Yes, fully independent channels
